Amphenol ICC Quickie Series Straight Cable PCB Socket, 16-Contact, 2 Row, 2.54 mm Pitch IDC 71600-116LF

Amphenol ICC 71600-116LF is a Quickie Series Straight Cable PCB Socket featuring 16 contacts in 2 rows with a 2.54 mm pitch. It is an IDC receptacle connector designed for wire-to-board connections in electronic assemblies, providing reliable terminations for flat flexible cables with wire sizes ranging from 30 AWG to 26 AWG.

The connector housing is made from polyethylene terephthalate, ensuring robust mechanical performance. The gold-plated phosphor bronze contacts provide excellent conductivity and corrosion resistance. An adjustable bridge type cover protects the contacts while simplifying cable assembly through an accurate cover-to-base alignment, which together with polarization slots prevents mismating.

This 1A rated connector withstands voltages up to 1kV and operates in temperature extremes from -65°C to 105°C, making it ideal for demanding industrial, instrumentation, medical, consumer, communication, and data applications. The IDC terminals feature long wiping action for reliable electrical contact, and duplex plating supports up to 100 mating cycles, ensuring durable connectivity.

Part numbers with the prefix 71600-1 mate with specific shrouded latched headers, guaranteeing secure and reliable connections. These connectors are widely used in electronic equipment requiring compact, efficient, and durable PCB socket solutions.

Supports 1A current rating for reliable electrical performance. Constructed with polyethylene terephthalate housing for durability. Gold plated phosphor bronze contacts assure long-lasting connection integrity. Designed with an adjustable bridge type cover for simplified cable assembly.

Operates within a temperature range from -65°C to 105°C, suitable for harsh environments. Features polarization slots to prevent mismating and ensure accurate alignment. Rated for 1kV voltage handling capability for safe operation.

Duplex plating guarantees up to 100 mating cycles for high durability. Compatible with flat flexible cables wire sizes 30 AWG to 26 AWG.

These PCB Sockets are suitable for diverse industrial, laboratory, medical, communication, and consumer electronics applications. For further selection, explore related Amphenol ICC connectors and PCB socket components available on EnvMart.
