Wurth Elektronik Polypropylene Film Capacitor WCAP-FTXX Series 560nF 310V dc 310V ac Through Hole 890334026018CS
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | -40 °C to +105°C |
| Height | 16.5mm |
| Length | 26mm |
| Model | 890334026018CS |
| Width | 7.5mm |
| Mount Type | Through Hole |
| Series | WCAP-FTXX |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±10 % |
| Capacitance | 560nF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Solder |
| Dissipation Factor | 0.7% |
| Lead Length | 4mm |
| Standards/Approvals | cULus, ENEC, VDE, CQC |
| Package/Case | 500 |
| Rated AC Voltage | 310V ac |
| Rated DC Voltage | 310V dc |
| Lead Pitch | 22.5mm |
| Lead Diameter | 0.8mm |
| Applications include | Safety applications, Filter and Power Supplies |
| Suppression Class | X2 |
| KEMET F862 Polypropylene Film Capacitor, 310V ac, ±10%, 560nF, Through HoleBrand | KEMET |
Key Features
- This capacitor offers a tolerance of ±10% ensuring reliable performance.
- It supports an operating temperature range from -40°C up to 105°C.
- The lead pitch is 22.5mm with lead length of 4mm and lead diameter of 0.8mm for precise PCB mounting.
- Encapsulated in self-extinguishing material complying with UL94V-0 standard.
- Designed for safety applications, interference suppression coils, and EMI filters.
- Features self-healing metallized polypropylene dielectric film technology for enhanced durability.
- Complies with standards including cULus, ENEC, VDE, and CQC.
- Package case quantity of 500 units for bulk installation needs.
Product Description
Wurth Elektronik 890334026018CS is a polypropylene film capacitor belonging to the WCAP-FTXX series, engineered for demanding safety and EMC applications. Rated at 560nF capacitance with a tolerance of ±10%, this capacitor operates reliably at 310V DC and AC voltages. It is suitable for through-hole PCB mounting, facilitating robust electrical connections and mechanical stability.
This capacitor incorporates metallized polypropylene film known for its self-healing properties, which enhances operational reliability in circuits subjected to surges or transient voltages. Operating temperature ranges from -40°C to +105°C make it suitable for a wide variety of industrial and commercial electronic environments.
Designed following strict safety standards, the WCAP-FTXX is encapsulated in UL94V-0 rated self-extinguishing material, ensuring compliance with rigorous flammability requirements. Typical applications include safety-related circuits, interference suppression coils, EMI filters, and various power supply applications where reliability and circuit protection are critical.
Key physical features include a 22.5mm lead pitch, 4mm lead length, and 0.8mm lead diameter to fit standard PCB layouts. The package case includes 500 capacitors, making it ideal for volume manufacturing and maintenance purposes.
This capacitor provides stable capacitance with ±10% tolerance for precision filtering and suppression. Wide operating temperature range enables use across diverse environmental conditions. Compliance with international standards such as cULus, ENEC, VDE, and CQC ensures global acceptance and safety.
Self-healing dielectric material prolongs capacitor life under electrical stress. Encapsulation in flame-retardant material enhances safety in applications. Dimensions and lead specifications support easy PCB mounting and effective circuit integration.
Suitable for industrial, electronics manufacturing, power supply, and filter applications.
Wurth Elektronik capacitors are trusted in industrial, commercial, and electronic component sectors. Explore more Film Capacitors and related components in the Electronics & Electricals category on EnvMart for reliable electronic design solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this capacitor is 560nF.
It operates within a temperature range of -40°C to +105°C.
The capacitor is rated for 310V DC and 310V AC.
The lead pitch is 22.5mm, and the lead diameter is 0.8mm.
It has a tolerance of ±10%.
This model supports through-hole mounting.
It is encapsulated in self-extinguishing material that complies with the UL94V-0 standard.
It is suitable for safety applications, interference suppression coils, EMI filters, and power supplies.
The dimensions are 26mm in length, 7.5mm in width, and 16.5mm in height.
It complies with cULus, ENEC, VDE, and CQC standards.
The package case includes 500 units.
The dissipation factor is 0.7%.
