Wurth Elektronik WR-MPC3 Series Straight Through Hole PCB Header, 8 Contacts, 3 mm Pitch, 1 Row, Shrouded MPC3
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 5A |
| Model | MPC3 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Series | WR-MPC3 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3mm |
| Contact Plating | Tin |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.18mm |
Key Features
- The connector features 8 male contacts with a 3.18 mm tail pin length.
- Designed for through-hole mounting with a straight orientation.
- Housing is constructed from UL94-V0 black PA9T liquid crystal polymer.
- Rated for 5A current and 250V voltage operation.
- Operating temperature range is from -40°C to 105°C for versatile industrial use.
- Contacts are copper alloy with tin plating ensuring durable electrical performance.
- Shrouded design protects contacts and ensures secure mating with female receptacle housings.
- Suitable for industrial applications requiring wire-to-board connections with high reliability.
Product Description
Wurth Elektronik MPC3 Straight Through Hole PCB Header, model MPC3, features 8 male contacts in a single row with a 3 mm pitch. This shrouded header is designed for through-hole mounting, making it ideal for reliable wire-to-board electrical connections in electronics and industrial equipment.
The connector's housing is made from UL94-V0 rated black PA9T liquid crystal polymer, offering high resistance to heat and flame. The copper alloy stamped contacts are tin plated to provide excellent conductivity and corrosion resistance. Tail pin length measures 3.18 mm for secure solder connection.
With a current rating of 5A and voltage rating of 250V, this PCB header performs well under demanding electrical loads. Its operating temperature range of -40°C to 105°C enables use in varied environmental conditions found in manufacturing, industrial electronics, HVAC controls, and power distribution systems.
The shrouded design safeguards contacts and ensures secure mating with complementary single row female receptacle housings from the WR-MPC3 series. This feature promotes durability and stability in electrical assemblies.
This PCB header is a vital component for engineers and technicians designing and assembling industrial electronics, automation systems, and power equipment where robust wire-to-board connectors are essential.
The connector features 8 male contacts with a 3.18 mm tail pin length. Designed for through-hole mounting with a straight orientation. Housing is constructed from UL94-V0 black PA9T liquid crystal polymer. Rated for 5A current and 250V voltage operation.
Operating temperature range is from -40°C to 105°C for versatile industrial use. Contacts are copper alloy with tin plating ensuring durable electrical performance. Shrouded design protects contacts and ensures secure mating with female receptacle housings.
Suitable for industrial applications requiring wire-to-board connections with high reliability. Explore the range of Wurth Elektronik PCB Headers and connectors at EnvMart for high-quality and reliable electronic component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 5A and a voltage of 250V, making it suitable for various electrical applications.
The header features a 3 mm pitch and has 8 male contacts arranged in a single row.
The housing is made from UL94-V0 rated black PA9T liquid crystal polymer, and the contacts are copper alloy with tin plating.
It operates within a temperature range of -40°C to 105°C, suitable for various industrial environments.
This unit is designed for through-hole mounting, allowing for secure installation on printed circuit boards.
The tail pin length for the contacts is 3.18 mm, which facilitates a secure solder connection.
It utilizes a wire-to-board connector system, making it suitable for reliable electrical connections in various applications.
This model features a shrouded design, which protects the contacts and ensures secure mating with compatible female receptacles.
It supports solder termination, which is common for securing connections on printed circuit boards.
It is suitable for industrial applications requiring reliable wire-to-board connections, including manufacturing and power distribution systems.
The country of origin for this PCB header is India.
