Wurth Elektronik WR-MPC4 Series Straight Through Hole PCB Header, 4 Contact, 4.2 mm Pitch, 2 Row, Shrouded MPC4
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 600V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 69A |
| Model | MPC4 |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | WR-MPC4 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 4.2mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.5mm |
Key Features
- Features a shrouded 2 row design for secure mating.
- Constructed with polyamide housing material for durability.
- Operates safely up to 600 V and 69 A current rating.
- Contacts are made of copper alloy plated with tin over nickel.
- Supports operating temperature range from -40°C to 105°C.
- Tail pin length measures 3.5 mm for effective soldering.
- Designed for through hole mounting ensuring strong mechanical and electrical connection.
Product Description
Wurth Elektronik MPC4 is a straight through hole PCB header designed for high reliability wire-to-board connections in electronic circuits. It features 4 contacts arranged in 2 rows with a pitch of 4.2 mm, combining compact size with robust performance.
The connector uses a shrouded housing made of UL94-V0 rated white nylon 66 polyamide material, providing excellent insulation and mechanical stability. Copper alloy contacts are plated with tin over nickel to ensure low contact resistance and corrosion resistance. The contact tail pins are 3.5 mm long, optimized for soldering reliability on PCB boards.
This PCB header supports high current loads up to 69 A and voltages up to 600 V, making it suitable for demanding power and signal applications. It can operate efficiently over a wide temperature range from -40°C to 105°C, ensuring performance in industrial and commercial environments.
The through hole mount type ensures a secure mechanical attachment to printed circuit boards, suitable for assembly in various electronic devices and systems. Its straight orientation allows easy mating with corresponding female receptacle housings, particularly the WR-MPC4 4.20 mm dual row female connectors.
Wurth Elektronik MPC4 is widely used in electronic manufacturing, power distribution boards, industrial machinery, and automotive electronics, providing reliable and durable connections that withstand mechanical and environmental stresses.
Features a shrouded 2 row design for secure mating. Constructed with polyamide housing material for durability. Supports operating temperature range from -40°C to 105°C. Contacts are copper alloy plated with tin over nickel for corrosion resistance.
Current rating up to 69 A with voltage capacity of 600 V. Tail pin length of 3.5 mm optimized for soldering. Suitable for through hole mounting and wire-to-board connector systems. Explore further products in the PCB Headers category for compatible connectors and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of up to 69 A, making it suitable for high current applications.
It operates safely at voltages up to 600 V, which is ideal for various electronic applications.
The contacts are arranged with a pitch of 4.2 mm, allowing for compact connections on PCBs.
The housing is made from polyamide, while the contacts are copper alloy plated with tin over nickel for corrosion resistance.
It can operate efficiently within a temperature range of -40°C to 105°C, suitable for various environments.
The tail pin length measures 3.5 mm, optimized for reliable soldering on PCB boards.
This unit is designed for through hole mounting, ensuring a secure mechanical connection to printed circuit boards.
It features 4 contacts arranged in 2 rows, providing multiple connection points in a compact design.
The connector has a straight orientation, facilitating easy mating with corresponding female receptacle housings.
This model is designed for wire-to-board connections, making it suitable for various electronic applications.
Yes, it features a shrouded design which enhances the security of the mating connections.
The country of origin for this product is Taiwan.
