Wurth Elektronik WR-MPC4 Series Straight Through Hole PCB Header 8 Contacts 4.2 mm Pitch 2 Row Shrouded MPC4
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 600V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 69A |
| Model | MPC4 |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | WR-MPC4 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 4.2mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.5mm |
Key Features
- Offers a 4.2 mm pitch dual-row male header for secure wire-to-board connection.
- Constructed with polyamide housing ensuring durable insulation properties.
- Features copper alloy contacts plated with tin over nickel for corrosion resistance.
- Operates reliably between -40°C to 105°C temperature range.
- Supports up to 69A current rating and 600V voltage for demanding applications.
- Designed for through-hole mounting with 3.5 mm tail pin length for robust solder connections.
- Shrouded design enhances contact protection and prevents incorrect mating.
- Complies with no specific certifications but meets industry design standards.
Product Description
Wurth Elektronik MPC4 Series Straight Through Hole PCB Header model MPC4 is a high quality dual-row 8-contact male header with 4.2 mm pitch designed for printed circuit board applications. This shrouded component provides a reliable wire-to-board connection, featuring a polyamide white UL94-V0 insulator for superior electrical insulation and mechanical stability under demanding industrial conditions.
The contacts are constructed from copper alloy and plated with tin over nickel, delivering excellent conductivity and corrosion resistance. The header supports a maximum current of 69A and voltage of up to 600V, suitable for power electronics and industrial control circuits. Operating temperature ranges from -40°C up to 105°C ensures consistent performance in various environmental conditions.
This component is through-hole type with a 3.5 mm tail pin length for secure solder joint formation on PCB. The shrouded design prevents misalignment and enhances user safety during connector mating. With two rows of contacts spaced at 4.2 mm pitch, this header is compatible with matching female receptacle housings in WR-MPC4 series.
Typical industrial use cases include electronic manufacturing, power control systems, telecommunications equipment, and complex automation machinery. This connector is engineered to ensure long-lasting and robust electrical connections in commercial and industrial environments.
4.2 mm dual row pitch male header with 8 contacts. Polyamide housing with UL94-V0 flame rating for safety. Copper alloy contacts plated with tin over nickel for durability. Through-hole mount with 3.5 mm tail pin length for soldering.
Operates reliably in -40°C to 105°C temperature range. Rated for 69A current and 600V voltage maximum. Shrouded construction for protection and alignment. Manufactured in Taiwan ensuring consistent quality. Explore the Electronics Components category to find more Wurth Elektronik connectors and PCB Headers for your design and manufacturing needs on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current rating of 69A, making it suitable for demanding applications.
It is rated for a maximum voltage of 600V, which is appropriate for power electronics and industrial control circuits.
The header features a 4.2 mm pitch and has 8 contacts arranged in a dual-row configuration.
The housing is made from polyamide, while the contacts are constructed from copper alloy and plated with tin over nickel for corrosion resistance.
It operates reliably within a temperature range of -40°C to 105°C, ensuring consistent performance in various environments.
This model is designed for through-hole mounting, featuring a tail pin length of 3.5 mm for secure solder connections.
It utilizes a wire-to-board connector system, providing a reliable connection between wires and the PCB.
Yes, the shrouded design enhances contact protection and prevents incorrect mating during connection.
The Wurth Elektronik WR-MPC4 series header is manufactured in Taiwan, ensuring consistent quality.
The termination type is solder, allowing for robust connections on the PCB.
While it does not comply with specific certifications, it meets general industry design standards for PCB headers.
Typical applications include electronic manufacturing, power control systems, telecommunications equipment, and complex automation machinery.
