onsemi Voltage Regulator 20V SOT-223 4-Pin NCP1117STAT3G

onsemi NCP1117STAT3G is a high-performance LDO (Low Dropout) linear voltage regulator designed to deliver stable 20V output with an output current capacity exceeding 1A. Packaged in a compact SOT-223 4-pin surface mount form factor, it offers reliable voltage regulation with enhanced dropout voltage and temperature stability.

The device is optimized for applications in consumer electronic devices and industrial equipment requiring efficient power management. Its design includes fixed and adjustable voltage options, allowing output voltage to be programmed from 1.25V up to 18.8V with low dropout characteristics (maximum 1.2V at 800mA load).

Key features of the NCP1117STAT3G include a low quiescent current of 10mA, built-in current limiting, and thermal shutdown protection ensuring safe operation under fault conditions. Compliance with automotive standard AEC-Q100 assures suitability for automotive electronics integration.

This voltage regulator is well suited for use in battery chargers, hard drive controllers, SCSI termination circuits, and switching power supply post regulation. The 3.7mm by 6.7mm by 1.69mm SOT-223 package height and width supports compact PCB layouts. It can reliably operate at maximum temperatures up to 125°C.

Output current in excess of 1A with low dropout voltage. Fixed and variable voltage regulator options available. 1.2V maximum dropout voltage at 800mA load current. Current limit and thermal shutdown protection integrated.

Automotive grade with AEC-Q100 qualification. Quiescent current typical 10mA for energy efficient operation. Compact 4-pin SOT-223 surface mount package. Wide operating temperature range to 125°C. Application versatility including consumer and industrial use.

Suitable for battery chargers, point of regulation, and power management circuits. Discover more power management solutions and Voltage Regulators at EnvMart for your industrial, automotive, and consumer electronics projects.
