onsemi Voltage Regulator 625mW 40V dc SOIC 8-Pin MC78L15ACDR2G

onsemi MC78L15ACDR2G is a reliable and efficient linear voltage regulator designed for precision voltage regulation in various electronic circuits. It belongs to the MC78L00A series and is packaged in a compact SOIC 8-pin surface mount package, facilitating easy integration into PCB designs. With a power rating of 625mW and a maximum input voltage of 40V DC, it supports stable voltage regulation across a wide range of applications.

This voltage regulator features an internal thermal overload protection mechanism and current limiting features, providing enhanced robustness and safeguarding against damage under overcurrent or high-temperature conditions. It also includes safe area compensation, ensuring reliable operation across varying load conditions without external components.

Operating within an input voltage range from 16.7V up to 40V DC and capable of operating at temperatures up to 125°C, the MC78L15ACDR2G is well suited for challenging automotive and industrial environments. Its compliance with the AEC-Q100 automotive standard further assures superior performance and reliability in automotive electronics.

The device requires no external components for standard operation but allows external adjustments for voltage and current when needed, providing flexibility for specialized applications. Its compact footprint minimizes PCB space requirements, beneficial for high-density electronic assemblies.

Key applications of this voltage regulator include power management in industrial controls, automotive electronic circuits, consumer electronics, and embedded systems where precise and stable voltage supply is critical. Designed for positive polarity and surface mount installation, it provides a cost-effective and reliable solution for engineers.

Fixed 5V linear voltage regulator of the MC78L00A family by ON Semiconductor. Surface mount SOIC 8-pin package for compact and efficient PCB integration. Internal thermal overload and current limit protection for durable operation.

Complies with automotive standard AEC-Q100 for high reliability. Input voltage range between 16.7V and 40V DC for versatile applications. Quiescent current rating of 6.5mA optimizing power efficiency. Compact dimensions: 5mm length, 4mm width, and 1.5mm height.

Ideal for automotive, industrial, and consumer electronic power regulation. Explore the complete range of Voltage Regulators at EnvMart for all your power management IC needs.
