Crydom HDC Series Solid State Relay Panel Mount 120A Load Current 7-150V dc Load Voltage 4.5-32V dc Control HDC200D120
Specifications
| Country of Origin | India |
|---|---|
| Brand | Crydom |
| Height | 73.5mm |
| Length | 104mm |
| Model | HDC200D120 |
| Mount Type | Panel |
| Series | HDC |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -30°C |
| Terminal type | Quick Connect |
| Maximum Load Current | 120A |
| Standards/Approvals | RoHS |
| Maximum Load Voltage | 150V dc |
| Minimum Load Voltage | 7V dc |
| Minimum Control Voltage | 4.5V dc |
| Maximum Control Voltage | 32V dc |
| Off State Leakage Current | 0.2mA |
Key Features
- Features a green LED indicator for easy status monitoring.
- Supports a maximum load current of 120A suitable for powerful electrical systems.
- Operates over a wide temperature range from -30°C to 80°C, ensuring reliability in harsh environments.
- Quick connect terminal type allows for efficient installation and maintenance.
- Has a fast turn-on time between 12 and 92 microseconds for rapid switching applications.
- Turn-off time ranges between 195 and 405 microseconds enabling quick circuit deactivation.
- Lightweight design at approximately 340.2g reduces strain on mounting panels.
- RoHS compliant ensuring environmental safety and sustainability.
Product Description
Crydom HDC200D120 Solid State Relay panel mount device with a maximum load current of 120A and a load voltage range of 7 to 150V dc. This relay is designed for industrial and automation environments requiring high reliability and fast switching capabilities.
The unit features a green LED indicator that provides clear status monitoring for operators. Its solid-state construction eliminates moving parts, reducing mechanical wear and increasing durability.
Operating temperature ranges from -30°C to +80°C make this relay suitable for harsh environmental conditions. Its quick connect terminals facilitate easy wiring and maintenance in control panels.
The relay offers a fast turn-on time between 12 and 92 microseconds and a turn-off time between 195 and 405 microseconds, ideal for applications requiring rapid switching such as medical equipment, multiplexers, and I/O subsystems.
Green LED status indicator for operational monitoring. 120A rated load current for robust electrical systems. Wide operating temperature range from -30°C to 80°C. Quick connect terminals simplify installation. Rapid turn-on and turn-off times for efficient switching.
Lightweight at approximately 340.2 grams. RoHS compliant environmental standard. Compact dimensions: 104 mm length, 73.5 mm height. Applications include medical equipment and industrial control systems.
This Crydom solid state relay is a reliable choice for industrial automation, manufacturing, HVAC controls, laboratory equipment, and water treatment processes that require reliable DC load switching. The panel mount format eases integration into existing electrical systems.
Explore the full range of Crydom Solid State Relays and related electrical control components on EnvMart for trusted, high-quality solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this model is 120A, making it suitable for powerful electrical systems.
This relay operates over a wide temperature range from -30°C to 80°C, ensuring reliability in harsh environments.
The relay has a length of 104 mm and a height of 73.5 mm, making it compact for panel mounting applications.
It supports a load voltage range from 7 to 150V dc, accommodating various industrial applications.
This model features quick connect terminals, which simplify installation and maintenance.
The turn-on time for this relay ranges between 12 and 92 microseconds, suitable for rapid switching applications.
The turn-off time ranges between 195 and 405 microseconds, enabling quick circuit deactivation.
Yes, this model is RoHS compliant, ensuring it meets environmental safety and sustainability standards.
The off state leakage current is 0.2mA, which is a relevant specification for energy efficiency.
This solid state relay is suitable for applications such as medical equipment, industrial control systems, HVAC controls, and water treatment processes.
The relay weighs approximately 340.2 grams, which helps reduce strain on mounting panels.
The minimum control voltage required for this model is 4.5V dc, while the maximum is 32V dc.
