Microchip Surface Mount DC/DC Converter 15V Output Voltage 600 mA Output Current MCP16301T-I/CHY
Specifications
| Country of Origin | Thailand |
|---|---|
| Voltage | Converters / Switching Regulators Microchip DC/DC Converter, Surface, 15V Output |
| Brand | Microchip |
| Efficiency | 96% |
| Length | 3.1mm |
| Model | MCP16301T-I/CHY |
| Depth | 1.45mm |
| Width | 1.8mm |
| Mount Type | Surface |
| Series | MCP16301 |
| Output Current | 600mA |
| Maximum Operating Temperature | 85°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Input Voltage | 30V |
| Line Regulation | 0.1 %/V |
| Standards/Approvals | RoHS, ISO 9001, EIA/JESD51-3 |
| Minimum Input Voltage | 4V |
| Number of Pins | 6 |
| Output Voltage 1 | 15V |
Key Features
- The device supports surface mount installation for compact circuit integration.
- Input voltage ranges from 4 V minimum to 30 V maximum for versatile applications.
- Offers high efficiency of 96% to reduce power loss during conversion.
- Operates reliably within temperature range from -40°C to 85°C.
- Features a 6-pin SOT-23 package with dimensions 3.1 mm length, 1.8 mm width, and 1.45 mm depth.
- Includes line regulation performance of 0.1 %/V for stable output voltage.
- This single output converter uses MCP16301 series asynchronous buck topology.
- Conforms to RoHS, ISO 9001, and EIA/JESD51-3 standards ensuring quality and compliance.
Product Description
Microchip MCP16301T-I/CHY is a high-efficiency surface mount DC/DC converter designed to provide a regulated 15 V output voltage with a maximum output current of 600 mA. It operates from a wide input voltage range of 4 V to 30 V and achieves an efficiency of up to 96%, minimizing power dissipation in demanding electronic circuits.
The device is packaged in a compact 6-pin SOT-23 form factor, measuring 3.1 mm in length, 1.8 mm in width, and 1.45 mm in depth, making it suitable for densely packed printed circuit boards (PCBs). Its line regulation of 0.1 %/V ensures stable voltage output under varying input conditions.
Designed for robust performance, this converter functions reliably between -40°C and 85°C ambient temperature, supporting a wide range of industrial and commercial applications such as power supplies for embedded systems, telecommunications equipment, and general electronics requiring efficient power regulation.
The MCP16301 series employs an asynchronous buck topology, optimizing energy conversion efficiency and reducing external component count. Compliance with RoHS directives and ISO 9001 certification reflects Microchip's commitment to quality and environmental standards.
The device supports surface mount installation for compact circuit integration. Input voltage ranges from 4 V minimum to 30 V maximum for versatile applications. Offers high efficiency of 96% to reduce power loss during conversion.
Operates reliably within temperature range from -40°C to 85°C. Features a 6-pin SOT-23 package with dimensions 3.1 mm length, 1.8 mm width, and 1.45 mm depth. Includes line regulation performance of 0.1 %/V for stable output voltage.
This single output converter uses MCP16301 series asynchronous buck topology. Conforms to RoHS, ISO 9001, and EIA/JESD51-3 standards ensuring quality and compliance. Ideal for industrial, electronic component power supplies, and embedded device applications.
Microchip's MCP16301T-I/CHY DC/DC converter is a premium solution for engineers seeking reliable and efficient voltage conversion in surface mount package technology. Explore our category for more DC/DC Converter options from leading brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a regulated output voltage of 15 V.
The maximum output current for this unit is 600 mA.
It operates with an input voltage range from 4 V to 30 V.
It achieves an efficiency of up to 96%, minimizing power loss during conversion.
The package dimensions are 3.1 mm in length, 1.8 mm in width, and 1.45 mm in depth.
The line regulation performance is 0.1 %/V, ensuring stable output voltage under varying input conditions.
This unit operates reliably within a temperature range of -40°C to 85°C.
It features a single output.
It conforms to RoHS, ISO 9001, and EIA/JESD51-3 standards.
This converter employs an asynchronous buck topology.
The SOT-23 package has 6 pins.
The country of origin for this model is Thailand.
