Samtec TLW Series Straight Through Hole Pin Header 60 Contacts 2.54 mm Pitch 2 Row Unshrouded TLW-130-05-G-D

Samtec TLW-130-05-G-D is a high-quality PCB through hole pin header from the TLW Series, engineered for reliable electronic connections in various industrial and commercial applications. Featuring 60 male contacts arranged in 2 rows with a 2.54 mm pitch, this connector provides precise and secure board-to-board and wire-to-board mating options.

The housing is fabricated from black liquid crystal polymer, ensuring durability and thermal stability within its operating temperature range of -55°C to 125°C. The phosphor bronze contacts are plated with 0.25µm gold, enhancing conductivity and resistance against corrosion for long-lasting performance.

The pin header's termination type is solder, with a tail pin length of 4.32 mm designed for through-hole mounting on printed circuit boards, and a mating pin length of 2.67 mm that supports compatible socket connectors. Its unshrouded straight orientation allows versatile configuration and easy access for multiple connector systems.

This pin header supports current up to 3A, making it suitable for demanding electrical connections in industrial, laboratory, manufacturing, and electronic assembly processes.

Key features include low profile 2.54 mm square post terminals, excellent mechanical and electrical properties, and compatibility with standard socket strips for enhanced design flexibility.

Designed for board-to-board and wire-to-board connector systems. Housing made of durable black liquid crystal polymer for high reliability. Phosphor bronze contacts plated with 0.25µm gold for excellent conductivity and corrosion resistance.

Operates in temperature range from -55°C to 125°C. Solder termination with 4.32 mm tail pin length for secure PCB mounting. Low profile 2.54 mm square post header terminals with 2.67 mm mating pin length. Unshrouded straight orientation suitable for multiple connector configurations.

Supports current rating up to 3A for robust electrical performance. Explore more PCBs and electronic connectors in the Samtec TLW Series collection at EnvMart, engineered to meet stringent quality and performance standards.
