Wurth Elektronik WR-PHD Series Right Angle Through Hole Pin Header, 10 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 61301011021
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3mm |
| Mating Pin Length | 6mm |
Key Features
- Supports a current rating of 3A for reliable conductivity.
- Features a right angle orientation for versatile board mounting.
- Constructed with copper alloy contacts plated with gold for enhanced corrosion resistance.
- Designed for through hole mounting ensuring solid mechanical and electrical connection.
- Unshrouded design facilitates easy mating and demating.
- Suitable for board-to-board connector applications in electronic assemblies.
- Operates within a temperature range of -40°C to 105°C for demanding environments.
- Tail pin length is 3 mm; mating pin length is 6 mm for proper insertion depth.
Product Description
Wurth Elektronik 61301011021 WR-PHD Series Right Angle Through Hole Pin Header is engineered for robust and precise electronic board connections. Featuring 10 gold-plated copper alloy contacts arranged in a single row with a 2.54 mm pitch, this pin header ensures reliable signal transfer and excellent conductivity up to 3A current.
The right angle orientation facilitates flexible PCB layout and efficient space utilization in electronic device assemblies. Its through hole mount type guarantees secure mechanical fixation and optimal electrical performance during soldering processes.
Manufactured to operate over a wide temperature range from -40°C to 105°C, this pin header is well-suited for industrial, commercial, and consumer electronic applications requiring durability and longevity. The unshrouded design allows straightforward mating with compatible connectors to enable fast assembly and maintenance.
Constructed from high quality copper alloy with gold plating on contacts, the WR-PHD series offers superior corrosion resistance and minimal contact resistance, enhancing signal integrity. It is RoHS compliant, reflecting adherence to environmental directives and promoting safer electronic manufacturing practices.
Supports a current rating of 3A for reliable conductivity. Features a right angle orientation for versatile board mounting. Constructed with copper alloy contacts plated with gold for enhanced corrosion resistance. Designed for through hole mounting ensuring solid mechanical and electrical connection.
Unshrouded design facilitates easy mating and demating. Suitable for board-to-board connector applications in electronic assemblies. Operates within a temperature range of -40°C to 105°C for demanding environments. Tail pin length is 3 mm; mating pin length is 6 mm for proper insertion depth.
Compliance with RoHS standards ensures environmental safety.
This right angle pin header from Wurth Elektronik is ideal for use in manufacturing, electronics prototyping, and repair environments where superior electrical connection and resilience under varying conditions are critical. Browse more PCB Headers and Electronic Components at EnvMart to meet your assembly and design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 3A, ensuring reliable conductivity for electronic applications.
The contacts are arranged with a pitch size of 2.54 mm, suitable for standard PCB layouts.
It operates within a temperature range of -40°C to 105°C, making it suitable for demanding environments.
The WR-PHD Series pin header features 10 contacts, arranged in a single row.
This model is designed for through hole mounting, ensuring solid mechanical and electrical connections.
The contacts are constructed from copper alloy and are plated with gold for enhanced corrosion resistance.
The pin header features a right angle orientation, which allows for versatile board mounting.
The tail pin length is 3 mm, providing proper insertion depth for through hole applications.
The mating pin length is 6 mm, facilitating secure connections with compatible connectors.
Yes, this model is RoHS compliant, adhering to environmental directives for safer electronic manufacturing.
It is designed for board-to-board connector applications in electronic assemblies.
The termination type for this model is solder, ensuring reliable connections during assembly.
