Nexperia Zener Diode 2.7 V 550 mW 5% Tolerance Surface Mount 2-Pin SOD-323 BZX84J-C2V7,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Zener Diode 2.7 V 550 mW 5% Tolerance Surface Mount 2-Pin SOD-323 BZX84J-C2V7,115

Name: Nexperia Zener Diode 2.7 V 550 mW 5% Tolerance Surface Mount 2-Pin SOD-323 BZX84J-C2V7,115
Brand: Nexperia
SKU: 129336
Price: 0.05 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	0.8mm
Length	2.7mm
Model	BZX84J-C2V7,115
Mount Type	Surface
Series	BZX84J
Maximum Operating Temperature	150°C
Package Type	SOD-323
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	550mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	20μA
Nominal Zener Voltage Vz	2.7V
Zener Type	Voltage Regulator
Maximum Zener Impedance	100Ω
Typical Voltage Temperature Coefficient	-3.5mV/°C
- Non-repetitive Peak reverse power dissipation	40mW
- Total power dissipation	550mW
- Wide working voltage range	nominal 2.4V to 75V (E24 range)
- Two tolerance series	2% and 5%
ROHM 1, 2.9 V Zener Diode, Isolated 200 mW Surface 2-Pin SOD-323FBrand	ROHM

Key Features

The diode features a nominal Zener voltage of 2.7 V.
Maximum power dissipation is rated at 550 mW for reliable performance.
Tolerance of the Zener voltage is ±5%, enabling precise regulation.
Packaged in a compact surface mount SOD-323 2-pin package suitable for space-constrained designs.
Operating temperature range spans from -55°C to 150°C supporting industrial applications.
Low maximum reverse leakage current of 20 μA reduces power loss and noise.
Typical voltage temperature coefficient is -3.5 mV/°C for stable voltage over temperature.
Complies with automotive standard AEC-Q101, suitable for automotive electronics.

Product Description

Nexperia BZX84J-C2V7,115 Zener Diode is a single element voltage regulator diode packaged in a small surface mount 2-pin SOD-323 package. With a nominal Zener voltage of 2.7 V and total power dissipation of 550 mW, it serves as a reliable voltage regulator component for electronic circuits requiring precise voltage control.

This device supports industrial, automotive, and consumer electronics applications thanks to its AEC-Q101 automotive qualification and wide operational temperature range from -55°C to 150°C. The diode exhibits a low maximum reverse leakage current of 20 μA and a typical voltage temperature coefficient of -3.5 mV/°C, ensuring stable voltage regulation across varying environmental conditions.

The BZX84J series is designed for surface mount applications with its compact SOD-323 package, which is ideal for circuit boards with space limitations. It has a working voltage range spanning nominal 2.4 V to 75 V and is available with tolerance options of 2% and 5% to meet diverse precision requirements.

The diode configuration is single-element for discrete voltage regulation. Maximum power dissipation of 550 mW allows use in low to medium power circuits. Two-pin configuration simplifies mounting and circuit integration.

The device provides low differential resistance and wide working voltage range. Package height is approximately 0.8 mm and length 2.7 mm, promoting compact designs.

This product is manufactured in China and delivered as new condition. It is perfect for use in electronic circuits requiring Zener voltage regulation, automotive electronics, power supplies, and general purpose discrete semiconductor applications.
