Bourns 1210 Unshielded Wirewound Surface Mount Inductor, Ferrite Core, 47 μH ±10% 75 mA Idc Q:30 CM322522
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 2.2mm |
| Length | 3.2mm |
| Model | CM322522 |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | CM322522 |
| Maximum Operating Temperature | 100°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 47μH |
| Standards/Approvals | RoHS |
| Package/Case | 1210 |
| Maximum DC Current | 75mA |
| Pin Count | 2 |
| Maximum DC Resistance | 7Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 15MHz |
| Minimum Quality Factor | 30 |
| Inductor Construction | Wirewound |
Key Features
- Inductance of 47 microhenries with ±10% tolerance enhances circuit performance.
- Maximum DC current rating of 75 milliamperes ensures suitable handling of moderate currents.
- Compact 1210 package size with dimensions 3.2mm length, 2.5mm depth, and 2.2mm height.
- Constructed with a ferrite core and wirewound inductor construction for efficiency and durability.
- Suitable for applications in AV equipment, wireless communications, and general electronic equipment.
- Operating temperature range from -40°C to 100°C ensures versatility in various environments.
- Maximum DC resistance of 7 ohms maintains low power losses.
- Quality factor minimum of 30 and maximum self-resonant frequency of 15 MHz optimize performance.
Product Description
Bourns CM322522 1210 unshielded wirewound surface mount inductor with ferrite core, inductance of 47 μH ±10%, and a maximum DC current of 75 mA designed for high efficiency and reliability in electronic circuits.
This wirewound inductor features a robust ferrite core construction and is resin molded, providing excellent mechanical stability and performance consistency. The compact 1210 package size with dimensions of 3.2mm length, 2.5mm depth, and 2.2mm height facilitates easy integration into dense PCB layouts.
Rated for operation between -40°C to 100°C, this inductor can be reliably used in a range of industrial, communication, and consumer electronics applications including audio-visual equipment and wireless communication devices.
Key electrical characteristics include a maximum DC resistance of 7 ohms, a quality factor minimum of 30, and a maximum self-resonant frequency of 15 MHz that ensure stable inductive behavior across relevant frequencies.
Its solder termination style and tape & reel packaging make it suitable for automated manufacturing processes, promoting production efficiency and precise component placement. Inductance of 47 µH ±10% for stable circuit behavior.
Maximum DC current of 75 mA accommodates moderate power levels. Compact 1210 case size with small physical footprint. Ferrite core and wirewound construction enhance magnetic performance. Operating temperature range supports diverse environmental conditions.
Low DC resistance minimizes power loss in circuits. Quality factor and self-resonant frequency optimize frequency response. Solder termination and tape & reel packaging support automated assembly. This Surface Mount Inductor is RoHS compliant, ensuring adherence to environmental and safety standards.
Ideal for use in industrial electronics, communications equipment, surface mount PCB assemblies, and consumer electronics where space efficiency and reliable inductance are critical.
Explore the Electronics Components category at EnvMart to find more inductors and surface mount components that suit your technical and production needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 47 μH with a tolerance of ±10%.
The maximum DC current rating for this inductor is 75 milliamperes (mA).
The dimensions of the 1210 package are 3.2mm in length, 2.5mm in depth, and 2.2mm in height.
The operating temperature range for this model is from -40°C to 100°C.
The maximum DC resistance is 7 ohms, which helps maintain low power losses.
This inductor has a minimum quality factor of 30, which optimizes its performance.
The maximum self-resonant frequency for this inductor is 15 MHz.
The core material used in this inductor is ferrite, which enhances its efficiency.
This model features a solder termination style, suitable for automated assembly processes.
Yes, this surface mount inductor is RoHS compliant, adhering to environmental and safety standards.
This inductor is suitable for applications in AV equipment, wireless communications, and general electronic equipment.
The inductor is packaged in tape & reel format, facilitating easy handling and automated manufacturing.
