JAE IL-AG5 Series Right Angle Through Hole PCB Header 10 Contacts 2.5 mm Pitch 1 Row Shrouded IL-AG5-10P-S3L2

JAE IL-AG5-10P-S3L2 is a right angle through hole PCB header designed with 10 male contacts arranged in a single row featuring a 2.5 mm pitch. This shrouded connector uses high-quality brass contacts with tin plating to ensure optimal conductivity and corrosion resistance, and it incorporates a polybutylene terephthalate housing that delivers mechanical robustness and reliable insulation.

Engineered for automotive instrument panel applications, this connector supports current ratings up to 3 Amperes and is capable of operation in a broad temperature range from -40°C to 85°C. The right angle configuration helps optimize PCB layout efficiency in tight spaces.

The through hole mount type includes a mechanical lock for positive mating and a double lock mechanism to prevent accidental dislodging of contacts, ensuring secure and durable electrical connections. The shrouded design and unique housing configuration effectively minimize the risk of mis-mating with other connectors.

This PCB Header is a wire-to-board connector system utilizing solder termination to provide a stable, high-quality electrical interface. While no formal industry standards or approvals are specified for this model, its design reflects high reliability requirements typical for automotive and industrial electronic applications.

Applications for this product include automotive electronics, industrial controls, instrumentation, and general purpose electronics where dependable PCB interconnections are critical. The product can be paired with suitable housings and pin contacts such as those referenced by related RS stock items for complete connector solutions.

Designed for automotive instrument panel applications with high reliability. Rated for 3A current and operates from -40°C to 85°C temperature range. Polybutylene terephthalate housing ensures durable insulation and mechanical strength.

Brass male contacts plated with tin for excellent conductivity and corrosion resistance. Through-hole mount type with mechanical and double lock mechanisms to prevent contact dislodging. Right angle orientation facilitates compact PCB assembly.

Supports wire-to-board connector system with solder termination. Shrouded housing and unique design to help prevent mis-mating. Single-row 10 contact configuration with 2.5 mm row pitch. No industry standard approvals indicated for this model.
