STMicroelectronics 2-Channel Line Transceiver CMOS/TTL Surface Mount, 16-Pin TSSOP Package ST232CTR
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.2mm |
| Length | 5.1mm |
| Model | ST232CTR |
| Width | 4.48mm |
| Mount Type | Surface |
| Output type | CMOS/TTL |
| Series | ST232C |
| Input Type | Single Ended |
| Maximum Operating Temperature | 70°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | 0°C |
| IC Type | Line Transceiver IC |
| Number Of Channels | 2 |
| Pin Count | 16 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | CMOS/TTL |
| Logic Function | Line Transceiver |
| Minimum Supply Voltage | 4.5V |
| Maximum Propagation Delay Time @ CL | 1μs |
| Supply Current | 10mA |
Key Features
- Operates with a single-ended input and CMOS/TTL output signals.
- Supports two communication channels in one device.
- Designed to operate with supply voltages between 4.5V and 5.5V.
- Maximum propagation delay time of 1 microsecond at specified load capacitance.
- Surface mount type with a compact 16-pin TSSOP package.
- Operating temperature range from 0°C to 70°C for industrial applications.
- Low supply current consumption of 10mA enhancing power efficiency.
- Complies with no specific standards or automotive certifications.
Product Description
STMicroelectronics ST232CTR is a 2-channel RS-232 line transceiver IC featuring CMOS/TTL logic family and designed for easy integration into electronic systems. It is packaged in a space-saving 16-pin TSSOP package for surface mount applications. This transceiver supports single-ended inputs and CMOS/TTL outputs, making it suitable for line interface communications requiring efficient and reliable data transmission.
The device operates reliably over a supply voltage range of 4.5 to 5.5 volts and has a low supply current of 10mA, which supports energy-efficient industrial electronics and embedded systems. The propagation delay time of 1 microsecond at the rated load ensures swift communication responses in line applications.
Its operating temperature range from 0°C to 70°C makes it well-suited for standard industrial environments. The compact physical dimensions of 5.1mm length, 4.48mm width, and 1.2mm height allow for high-density PCB layouts in communication, instrumentation, and control systems.
This transceiver is ideal for use in industrial, electronic communication, measurement instruments, and embedded system applications requiring RS-232 standard Line Interface ICs. Applications include automotive electronics (non-automotive standard), instrumentation, and data communication devices.
Operates with CMOS/TTL logic levels supporting robust digital communication. Two-channel design enables dual line communication in one package. Surface mount TSSOP package facilitates automated assembly and compact design.
Wide supply voltage range and low power consumption enhance efficiency. Fast propagation delay minimizes communication latency. Suitable for industrial temperature range providing stable operation. Compact dimensions support space-constrained circuit boards.
Absence of automotive certifications indicates general industrial usage. Explore the full range of semiconductor interface ICs and line transceiver solutions at EnvMart for comprehensive industrial and commercial electronic applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range of 4.5V to 5.5V.
The dimensions of the ST232CTR are 5.1mm in length, 4.48mm in width, and 1.2mm in height.
The maximum propagation delay time is 1 microsecond at the specified load capacitance.
It supports two communication channels in one device.
The ST232CTR accepts single-ended input signals.
It provides CMOS/TTL output signals.
The operating temperature range is from 0°C to 70°C.
The supply current consumption is 10mA, which enhances power efficiency.
It comes in a compact 16-pin TSSOP package for surface mount applications.
This model is suitable for industrial, electronic communication, measurement instruments, and embedded system applications requiring RS-232 standard Line Interface ICs.
The logic family of the ST232CTR is CMOS/TTL.
The country of origin is India.
