HARWIN M20 Series Right Angle Through Hole PCB Socket 20-Contact 1 Row 2.54mm Pitch Solder Termination M20-7892046

The HARWIN M20-7892046 PCB Socket is a right angle, through-hole mounting connector designed for 2.54 mm pitch single row PCB applications. This 20-contact female socket provides a high-quality, compact solution for board-to-board connectivity in electronic manufacturing.

Its high temperature nylon housing (UL94V-0 rated) withstands reflow soldering and harsh operating environments, making it suitable for industrial, communications, consumer electronics, and embedded systems. The bronze contacts plated with tin over nickel ensure excellent electrical conductivity and long service life with a current rating of 12A per contact.

The dual beam contact system supports up to 300 mating cycles, improving connector reliability for frequent assembly and disassembly. The through-hole mount type and right angle orientation facilitate robust, space-efficient PCB design, addressing stringent height and density requirements.

Operating temperature range from -40°C to 105°C allows use in a wide range of environmental conditions. This RoHS compliant connector series reflects modern environmental and safety standards.

Applications for the M20-7892046 include consumer electronics, industrial monitoring, drive systems, and personal computing where reliable board-to-board connections are essential. Its compact and durable design is widely established as a standard in embedded PC and motherboard environments.

The socket features a right-angle orientation suitable for compact PCB layouts. Constructed from high temperature resistant nylon housing material. Contacts are made of bronze with tin over nickel plating for durability.

Rated for 12A current and supports up to 300 mating cycles. Operating temperature ranges from -40°C to 105°C for versatile industrial usage. Mount type is through-hole ensuring strong mechanical and electrical connection.

Designed to comply with RoHS standards for environmental safety. Highly durable dual beam contact design enhances electrical reliability. Ideal for consumer electronics, communications, industrial monitoring, and embedded PC applications.

Made in Taiwan, Province Of China with strict quality standards. Explore more from the HARWIN brand and find compatible electronic components at EnvMart for your industrial and manufacturing requirements.
