ASSMANN WSW 2.54 mm Pitch Vertical 8 Way Through Hole Turned Pin Open Frame DIL Socket 3A AR 08 HZL-TT

ASSMANN WSW AR 08 HZL-TT is a precision 8 Way Vertical DIL Socket with a 2.54 mm pitch designed for through-hole PCB mounting. It features turned pin open frame contacts providing reliable electrical connectivity up to 3A current and 100V ac voltage ratings. The socket housing is made of durable Polybutylene Terephthalate (UL94V-0) ensuring flame resistance and long-lasting service in electronics manufacturing and testing applications.

This open frame DIL Socket supports vertical orientation for compact PCB layouts and is terminated by soldering, offering robust mechanical and electrical performance. The contact pins composed of phosphor bronze and brass are tin-plated to resist corrosion and maintain conductivity. The component is rated for operation in a wide temperature range from -40°C to 105°C, making it suitable for industrial, laboratory, and commercial electronic devices.

With precise mechanical dimensions including a length and width of 10.16 mm and a depth of 3 mm, the AR 08 HZL-TT socket fits standard DIP ICs with 7.62 mm row spacing. It is a reliable choice in the assembly of electronic sensors, control modules, and testing rigs requiring frequent IC insertion and removal.

Compact 8 contact pins with a 2.54 mm pitch for precise component alignment. Vertical orientation for efficient PCB mounting and saving board space. Open frame design with a Polybutylene Terephthalate housing for durability.

Contacts made of phosphor bronze and brass with tin plating ensure excellent conductivity. Supports solder termination for secure and durable connections. Voltage rating of 100V ac suitable for various electronic circuits.

Operating temperature range from -40°C to 105°C for reliable performance under diverse conditions. Robust mechanical dimensions: length and width of 10.16 mm, depth of 3 mm, and row width of 7.62 mm. Manufactured in China with new product condition.

This ASSMANN WSW socket is widely used in industrial electronics, instrumentation, prototyping, and repair applications where durable and precise integrated circuit sockets are essential. It supports manufacturing efficiency by facilitating easy IC insertion and removal without soldering damage. Browse the Electronics & Electricals category at EnvMart for more quality electronic components and connectors from ASSMANN WSW.
