HARWIN Datamate L-Tek Series Right Angle Surface PCB Header, 16 Contact(s), 2 mm Pitch, 2 Row, Shrouded M80-8281642
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 120V |
| Brand | HARWIN |
| Orientation | Right Angle |
| Current | 3A |
| Model | M80-8281642 |
| Mount Type | Surface |
| Housing Material | Polyphenylene Sulphide |
| Contact Material | Phosphor Bronze |
| Series | Datamate L-Tek |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
Key Features
- Constructed with polyphenylene sulphide housing material for durability.
- Phosphor bronze contacts plated with gold ensure excellent conductivity.
- Rated for 3A current and 120V voltage for moderate power applications.
- Designed for surface mount technology with right angle orientation.
- Operates reliably from -55°C up to 125°C in harsh environments.
- Includes a friction latch ensuring secure and stable board-to-board or wire-to-board connections.
- Compatible with industry standard mounting and mating equivalents.
- Ideal for applications with high shock, vibration, and acceleration demands.
Product Description
HARWIN M80-8281642 Datamate L-Tek Series Right Angle Surface PCB Header is a high-reliability electronic connector designed for demanding industrial and commercial applications. It features 16 male contacts arranged in two rows with a precise 2 mm pitch, facilitating robust board-to-board and wire-to-board connections.
The connector housing is made from durable polyphenylene sulphide, offering excellent resistance against harsh environmental conditions such as vibration, shock, and temperature extremes ranging from -55°C to 125°C. The contacts are crafted from beryllium copper with gold plating, ensuring superior electrical performance and durability through many mating cycles. This design includes a friction latch for secure retention during assembly and operation.
Rated at 3A current and 120V voltage, this shrouded connector is suitable for applications requiring reliable power and signal integrity. It also complies with BS9525-F0033, MIL C 55302, and CEC 75101-008 standards, highlighting its suitability for critical and commercial off-the-shelf (COTS) applications.
This lateral insertion 180° SMT (surface mount technology) header is ideal for industrial, communications, and high-performance electronic device manufacturing. Its polarised mouldings prevent incorrect mating, further enhancing system reliability.
Durable polyphenylene sulphide housing for high mechanical stability. Beryllium copper gold-plated contacts for reliable, low resistance connections. Rated 3A current and 120V voltage for diverse applications. Shrouded, latched design to prevent misalignment and disconnections.
Operating range from -55°C to 125°C supports harsh environments. Right angle orientation suits compact PCB layouts. Surface mount technology for automated assembly processes. Complies with international standards for quality and reliability.
Manufactured in the United Kingdom ensuring high build quality.
The set contains one shrouded, dual-row PCB header with 16 male contacts and 2.0 mm pitch, suitable for board-to-board and wire-to-board connector systems. This product represents a reliable solution in electronics component categories for power connectors and specialized PCB Headers.
Explore the HARWIN category in EnvMart for more precision connectors and related products designed for electronic and power systems.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for 3A current and 120V voltage, making it suitable for moderate power applications.
The housing is constructed from polyphenylene sulphide, and the contacts are made from phosphor bronze with gold plating for enhanced conductivity.
It features 16 male contacts arranged in two rows with a 2 mm pitch.
This connector is designed for surface mount technology (SMT), allowing for automated assembly processes.
The design orientation is right angle, which is suitable for compact PCB layouts.
Yes, it includes a friction latch that ensures secure and stable board-to-board or wire-to-board connections.
It is compatible with board-to-board and wire-to-board connector systems, adhering to industry standards.
This product complies with BS9525-F0033, MIL C 55302, and CEC 75101-008 standards, indicating its reliability for critical applications.
The shrouded design helps to prevent misalignment and disconnections during use, enhancing reliability.
It is manufactured in the United Kingdom, ensuring high build quality.
This model uses solder termination, which is common for secure electrical connections.
