HARWIN Datamate L-Tek Series Right Angle Through Hole PCB Header, 3 Contacts, 2 mm Pitch, 1 Row, Shrouded M80-8420342
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 120V |
| Brand | HARWIN |
| Orientation | Right Angle |
| Current | 3A |
| Model | M80-8420342 |
| Mount Type | Through Hole |
| Housing Material | Polyphenylene Sulphide |
| Contact Material | Phosphor Bronze |
| Series | Datamate L-Tek |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3mm |
Key Features
- Features a shrouded, right angle design for secure mounting.
- Consists of 3 male contacts with gold-plated phosphor bronze material for optimal conductivity.
- Operates at a voltage of 120 V with a current rating of 3 A.
- Constructed with durable polyphenylene sulphide housing suitable for harsh environments.
- Supports a wide operating temperature range from -55°C to 125°C.
- Offers a 2 mm pitch and 3 mm tail pin length for precise PCB mounting.
- Designed to withstand high vibration, shock, and acceleration with long-lasting performance.
- Ideal for board-to-board and wire-to-board connector systems in industrial and electronic assembly.
Product Description
HARWIN M80-8420342 Datamate L-Tek Series Right Angle Through Hole PCB Header is engineered for robust and reliable electronic connections. This 3-contact, 2 mm pitch, single-row, shrouded male connector is built to meet rigorous requirements for industrial, laboratory, and commercial electronic applications.
The connector features a polyphenylene sulphide housing that ensures mechanical strength and chemical resistance, while the phosphor bronze contacts with gold plating provide excellent electrical conductivity and corrosion resistance. Its right angle orientation and through-hole mounting facilitate secure and stable PCB integration.
Designed to operate reliably from -55°C to 125°C, this connector supports a current of 3A and voltage rating of 120V, suitable for power and signal transmission in harsh environments. The tail pin length of 3 mm enhances soldering reliability for board assembly.
The Datamate L-Tek series is ideal for applications requiring high mating cycle durability and resistance to vibration and shock, including telecommunications, automotive, military, aerospace, and industrial equipment.
Features a shrouded design for improved connector protection and polarization. High-reliability four-finger beryllium copper contacts ensure secure connection integrity. Enables board-to-board and wire-to-board connections with industry-standard compatibility.
Meets compliance with BS9525-F0033, MIL C 55302, and CEC 75101-008 standards. Suitable for commercial off-the-shelf (COTS) and customised industrial solutions. Supports robust solder termination and secure mechanical fixation through its mounting style.
This product is manufactured in the United Kingdom and supplied in production pack tubes ideal for automated assembly processes. Its compact 2 mm pitch and single-row configuration make it an outstanding choice for densely packed PCB designs.
Discover more high-quality PCB connectors and Electronic Components at EnvMart, your trusted partner for industrial and electronic hardware solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates at a voltage of 120V and has a current rating of 3A.
This model features a 2 mm pitch and a tail pin length of 3 mm for precise PCB mounting.
The housing is made of polyphenylene sulphide, and the contacts are constructed from phosphor bronze with gold plating for enhanced conductivity.
It supports a wide operating temperature range from -55°C to 125°C.
It is designed for through-hole mounting, ensuring secure and stable integration onto the PCB.
It complies with BS9525-F0033, MIL C 55302, and CEC 75101-008 standards.
This connector features a right angle orientation, which facilitates easier routing of wires in tight spaces.
It consists of 3 male contacts, providing multiple connection points for electrical signals.
The shrouded design improves connector protection and polarization, enhancing connection integrity.
This product is manufactured in the United Kingdom.
It utilizes solder termination, which provides a reliable connection during PCB assembly.
