| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 3mm |
| Model | BZX84-C2V4,215 |
| Mount Type | Surface |
| Series | BZX84 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 250mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 50μA |
| Nominal Zener Voltage Vz | 2.4V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 100Ω |
| Typical Voltage Temperature Coefficient | -1.6mV/°C |
| onsemi, 2.4V Zener Diode 8% 300 mW SMT 3-Pin SOT-23Brand | ON Semiconductor |
Nexperia BZX84-C2V4,215 Zener Diode is a single diode designed as a voltage regulator with a nominal Zener voltage of 2.4 V and maximum power dissipation of 250 mW. It utilizes a surface mount mount type with a compact SOT-23 3-pin package, ideal for space-constrained electronic circuits.
The device supports operation in extreme temperature environments ranging from -65°C to 150°C, making it suitable for automotive, industrial, and electronic equipment applications requiring high reliability.
This diode features a typical voltage temperature coefficient of -1.6 mV/°C and a maximum Zener impedance of 100 Ω, ensuring stable voltage regulation and minimal variation over temperature changes.
The low maximum reverse leakage current of 50 μA enhances energy efficiency while maintaining performance integrity. It complies with the AEC-Q101 automotive standard, attesting to its robustness for automotive and harsh environment usage.
Its compact physical dimensions of 3 mm length and 1.1 mm height facilitate integration in compact PCB layouts for power regulation and protection circuits. Single diode configuration suitable for voltage regulation applications.
Nominal Zener voltage of 2.4 V with a tolerance of ±5%. Power dissipation capacity of 250 mW for steady operation. Surface mount type in SOT-23 package with 3 pins. Wide operating temperature range from -65°C to 150°C. Low maximum reverse leakage current of 50 μA for efficient performance.
Automotive standard compliance AEC-Q101 for enhanced reliability. Voltage temperature coefficient of -1.6 mV/°C for stable regulation. Compact size with 3 mm length and 1.1 mm height. Maximum Zener impedance of 100 Ω for precise voltage clamping.
This Zener diode is used extensively in electronic circuits for voltage regulation, protection, and reference voltage in equipment across automotive, industrial, laboratory, and manufacturing domains.
Explore more products in the Zener Diodes category on EnvMart for diverse semiconductor component needs.
