TE Connectivity Micro MATE-N-LOK Series Straight Through Hole PCB Header 20 Contacts 3 mm Pitch 2 Row Shrouded 5A 5-794630-0

TE Connectivity 5-794630-0 Micro MATE-N-LOK Series Straight Through Hole PCB Header is a high-quality wire-to-board connector system designed with 20 male contacts arranged in 2 rows at a 3 mm pitch. This connector features a shrouded black nylon housing that is 94V-0 rated for safety and durability. It operates reliably with a maximum current of 5A and voltage rating of 250V, suitable for demanding industrial and commercial electronic applications.

The header uses brass contact material plated with tin to ensure good conductivity and corrosion resistance. Its straight orientation and through-hole mounting approach include boardlocks and solder tail retention features, providing secure connections on printed circuit boards. The solder termination type with 3.56 mm tail pin length offers compatibility with standard soldering processes.

Operating temperature ranges from -40°C to 105°C, accommodating various environments including household appliances, lighting equipment, factory automation systems, data storage, and security systems. The Micro MATE-N-LOK system uses polarization and positive lock tabs to prevent mis-mating and secure cable connection. This makes it a reliable choice in applications where connection integrity is critical.

Available in standard vertical and right angle configurations, these headers are IR reflow process compatible, improving manufacturing efficiency. Low profile versions with less than 4.7 mm mating height are also offered, tailored for LED lighting applications among others.

High reliability and performance guaranteed by quality materials and design. Polarization prevents incorrect mating, ensuring connection safety. Positive lock tabs secure the header to the cable connector firmly. Through-hole mount with boardlocks or solder tail retention gives secure PCB fixing.

Suitable for industrial, commercial, and household electronic applications.

This 5-794630-0 header model is manufactured in China and is a trusted component for multiple electronics manufacturing sectors. It assures stable electrical performance and mechanical integrity across its operating range.
