STMicroelectronics 1-Element Bi-Directional TVS Diode 1.5 kW Surface Mount 2-Pin SMC SM15T22CA

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics 1-Element Bi-Directional TVS Diode 1.5 kW Surface Mount 2-Pin SMC SM15T22CA

Name: STMicroelectronics 1-Element Bi-Directional TVS Diode 1.5 kW Surface Mount 2-Pin SMC SM15T22CA
Brand: STMicroelectronics
SKU: 121871
Price: 0.38 USD
Availability: InStock



Category TVS Diode Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	2.45mm
Length	7.15mm
Model	SM15T22CA
Width	6.25mm
Mount Type	Surface
Series	SM15T TVS
Maximum Operating Temperature	150°C
Package Type	SMC
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Clamping Voltage VC	39.3V
Diode Configuration	Single
Direction Type	Bi-Directional
Minimum Breakdown Voltage Vbr	20.9V
Maximum Reverse Stand-off Voltage Vwm	18.8V
Peak Pulse Power Dissipation Pppm	1.5kW
Test Current It	1mA
Maximum Peak Pulse Current Ippm	254A
Maximum Reverse Leakage Current	1μA

Key Features

Single diode element configuration providing bidirectional voltage protection.
Peak pulse power dissipation rating of 1.5 kW for robust surge handling.
Clamping voltage of 39.3 V ensures reliable voltage limiting during transients.
Minimum breakdown voltage of 20.9 V supports circuit protection requirements.
Surface mount SMC package offers compact size with dimensions of approx. 7.15mm length by 6.25mm width.
Wide operating temperature range from -55°C to 150°C for demanding environments.
Rated maximum reverse stand-off voltage at 18.8 V suited for protecting DC rails and lines.
Maximum peak pulse current of 254 A suitable for transient suppression in industrial electronics.

Product Description

STMicroelectronics SM15T22CA is a high-performance 1-Element Bi-Directional Transient Voltage Suppression (TVS) diode engineered to protect sensitive electronic circuits from voltage surges and transient energy. Packaged in a compact Surface Mount 2-Pin SMC type package, this diode delivers a peak pulse power dissipation of 1.5 kW, making it suitable for transient voltage suppression in a range of industrial, commercial, and consumer electronics applications.

This device features a single diode element with bidirectional voltage clamping capability, which protects circuits by redirecting surge energy during voltage transients. It has a minimum breakdown voltage (Vbr) of 20.9 V, a maximum reverse stand-off voltage (Vwm) of 18.8 V, and clamps voltage at 39.3 V, ensuring reliable suppression levels for both positive and negative transients.

The SM15T22CA can operate reliably across a wide temperature range from -55°C to 150°C, making it appropriate for harsh operating environments commonly found in industrial electronics, HVAC control systems, power supplies, and more. Its low maximum reverse leakage current of 1μA contributes to energy efficiency in standby applications.

Typical uses include protection of power lines, data lines, and signal lines against transient surges caused by lightning strikes, inductive load switching, and electrostatic discharge (ESD). Its peak pulse current rating of 254 A ensures it can handle high surge currents without damage.

The diode is supplied in a surface mount package measuring 7.15 mm by 6.25 mm, facilitating easy PCB assembly and high-density layouts. Although it does not comply with automotive standards, it is well-suited for industrial and consumer electronics transient voltage suppression needs.

Single diode element and bi-directional configuration. Peak pulse power rating of 1.5 kW for surge suppression. Clamping voltage 39.3 V for controlled voltage limiting. Wide operating temperature from -55°C to 150°C for reliability.

Low leakage current of 1 μA reduces power loss. Compact SMC package for surface mount assembly. Suitable for industrial, consumer electronics, and power supply protection. Explore the range of TVS Diodes and related semiconductor components at EnvMart for all your electronic circuit protection requirements.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The SM15T22CA has a peak pulse power dissipation rating of 1.5 kW, making it suitable for robust surge handling.

The clamping voltage for the SM15T22CA is 39.3 V, which ensures reliable voltage limiting during transients.

The minimum breakdown voltage (Vbr) of the SM15T22CA is 20.9 V, supporting circuit protection requirements.

The maximum reverse stand-off voltage (Vwm) for the SM15T22CA is 18.8 V, making it suitable for protecting DC rails and lines.

This model has a maximum peak pulse current rating of 254 A, suitable for transient suppression in industrial electronics.

The SM15T22CA comes in a surface mount SMC package with dimensions of approximately 7.15 mm in length and 6.25 mm in width.

This diode operates reliably across a wide temperature range from -55°C to 150°C, suitable for demanding environments.

The maximum reverse leakage current for the SM15T22CA is 1 μA, contributing to energy efficiency in standby applications.

The SM15T22CA features a single diode element with a bi-directional configuration for voltage clamping.

This model is suitable for protecting power lines, data lines, and signal lines against transient surges caused by lightning strikes and electrostatic discharge (ESD).
