STMicroelectronics Operational Amplifier 1.3 MHz 5-Pin 6V SOT-23 LMV321RILT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.3mm |
| Length | 3mm |
| Model | LMV321RILT |
| Width | 1.75mm |
| Mount Type | Surface |
| Series | LMV321 |
| Output Current | 46mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS |
| Pin Count | 5 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 1.3MHz |
| Input Bias Current | 95 nA |
| Vos - Input Offset Voltage | 6 mV |
| Slew Rate | 0.45V/μs |
| Input Offset Current | 25 nA |
| Low supply current | 145 μA |
| Gain bandwidth product | 1 MHz |
| Electrostatic Discharge (ESD) tolerance | 2 kV |
Key Features
- Single channel operational amplifier with a gain bandwidth of 1.3 MHz.
- Low supply current consumption of 145 μA suitable for battery-powered devices.
- Rail-to-rail input and output capability for full signal swing.
- Input offset voltage of 6 mV and input bias current of 95 nA for precision applications.
- Slew rate of 0.45 V/μs ensures moderate response speed.
- Wide operating temperature range from -40°C to 125°C for harsh environments.
- Electrostatic discharge tolerance of 2 kV enhances device robustness.
- Compliant with RoHS environmental standards and meets automotive AEC-Q100 requirements.
Product Description
STMicroelectronics LMV321RILT is a single-channel, low power operational amplifier designed for a wide range of applications including portable and battery-powered equipment. This device offers a gain bandwidth product of 1.3 MHz and operates with a supply voltage range from 3 V up to 6 V.
The operational amplifier features rail-to-rail input and output capabilities, optimizing the signal range within low-voltage systems. With a low supply current consumption of only 145 μA, it is ideal for applications where power efficiency is critical.
Precision parameters such as an input offset voltage of 6 mV, input bias current of 95 nA, and an input offset current of 25 nA contribute to stable and accurate signal amplification. A slew rate of 0.45 V/μs facilitates satisfactory dynamic response in many signal conditioning tasks.
Robustness is ensured thanks to its electrostatic discharge tolerance of 2 kV and compliance with automotive AEC-Q100 standards, making it suitable for automotive electronics and industrial use cases. Additionally, its wide operating temperature range from -40°C to 125°C supports reliable performance under demanding environmental conditions.
The compact SOT-23 package (3 mm x 1.75 mm x 1.3 mm) offers space-saving integration in circuit boards. The device is RoHS compliant, reflecting environmental safety standards. Single channel operational amplifier with a gain bandwidth of 1.3 MHz.
Low supply current consumption of 145 μA suitable for battery-powered devices. Rail-to-rail input and output capability for full signal swing. Input offset voltage of 6 mV and input bias current of 95 nA for precision applications.
Slew rate of 0.45 V/μs ensures moderate response speed. Wide operating temperature range from -40°C to 125°C for harsh environments. Electrostatic discharge tolerance of 2 kV enhances device robustness. Compliant with RoHS environmental standards and meets automotive AEC-Q100 requirements.
Small physical dimensions with 3 mm length, 1.75 mm width, and 1.3 mm height. Maximum output current of 46 mA suitable for various interface needs.
This operational amplifier is widely used in industrial, automotive, consumer electronics, instrumentation, and measurement systems where low power consumption, space saving, and reliable signal amplification are critical factors.
Explore more Operational Amplifiers and semiconductors on EnvMart for all your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 1.3 MHz.
This model operates with a supply voltage range from 3 V to 6 V.
The maximum output current is 46 mA, suitable for various interface needs.
The input offset voltage is 6 mV, contributing to stable signal amplification.
It has a wide operating temperature range from -40°C to 125°C.
This operational amplifier comes in a compact SOT-23 package.
The input bias current is 95 nA, which is important for precision applications.
The slew rate is 0.45 V/μs, ensuring moderate response speed.
Yes, it is RoHS compliant and meets automotive AEC-Q100 requirements.
The electrostatic discharge tolerance is 2 kV, enhancing device robustness.
This operational amplifier has a single channel configuration.
The dimensions are 3 mm in length, 1.75 mm in width, and 1.3 mm in height.
