Pepperl + Fuchs Threaded Barrel Ultrasonic Proximity Sensor M30 x 1.5 2000 mm 200mA NPN 30V UB2000-30GM-E4-V15
Specifications
| Country of Origin | India |
|---|---|
| Brand | Pepperl + Fuchs |
| Response time | 145ms |
| Length | 94mm |
| Model | UB2000-30GM-E4-V15 |
| IP Rating | IP65 |
| Width | 36mm |
| Housing Material | Nickel Plated Brass |
| Output type | NPN |
| Series | UB2000 |
| Maximum Operating Temperature | 70°C |
| Thread Size | M30 x 1.5 |
| Minimum Operating Temperature | -25°C |
| Switching Current | 200mA |
| Terminal type | Connector-V15 |
| Body Style | Threaded Barrel |
| Maximum dc Voltage | 30V dc |
| Maximum Switching Frequency | 3.3Hz |
| Standards/Approvals | EN 60974-5-2 |
| Maximum Supply Voltage | 30V |
| Maximum Detection | 2000mm |
| Switch, proximity, M30, ultrasonic, 6000mm, NPNBrand | Pepperl + Fuchs |
Key Features
- Robust nickel plated brass housing with IP65 protection suitable for industrial environments.
- Operating temperature range from -25°C to 70°C for diverse applications.
- Connector type is Connector-V15 with 36mm width and 94mm length for compact mounting.
- Maximum switching frequency of 3.3Hz with a response time of 145ms ensures precise detection.
- Includes multiple output functions and programmable switching distances using a built-in programmer.
- Insensitive to compressed air and features temperature compensation for reliable operation.
- Short circuit and overload protected with LED status indicators for easy troubleshooting.
- Designed for use in automation, manufacturing, and control systems requiring accurate proximity sensing.
Product Description
Pepperl + Fuchs UB2000-30GM-E4-V15 threaded barrel ultrasonic proximity sensor features a robust M30 x 1.5 nickel plated brass body designed for industrial automation applications. It offers up to 2000 mm maximum detection range and operates on a 30V DC supply with a 200mA maximum switching current. Its NPN output type and fast response time of 145 ms make it suitable for precise object detection tasks.
The sensor is rated IP65 for protection against dust and water ingress, supporting operation in harsh factory environments. It supports multiple programmable output functions and switching distances, configurable via an easy-to-use built-in programmer interface, eliminating the need for external linking cables.
Operating reliably between -25°C and +70°C, this Ultrasonic Proximity Sensor includes features like synchronization, deactivation, temperature compensation, and is insensitive to compressed air, enhancing versatility and durability.
The Nickel plated brass housing ensures robustness and long service life. Connector type is M12 5-pin Plug-In compatible. Oversight standards include EN 60974-5-2, ensuring compliance with industrial norms.
Applications include automation systems, manufacturing process control, material handling detection, and machinery safety monitoring. IP65 protection makes it suitable for industrial, laboratory, and commercial environments.
Robust threaded barrel design for secure mounting. Programmable switching and multiple output functions. Temperature range and environmental protection for harsh conditions. Fast response with 145 ms cycle time. Compatible with M12 plug-in connections.
Explore a wide range of Pepperl + Fuchs sensors and proximity detection devices on EnvMart for your automation and control requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum detection range of the Pepperl + Fuchs UB2000-30GM-E4-V15 is 2000 mm.
This model has a response time of 145 ms, allowing for precise detection.
The sensor features an NPN output type, suitable for various automation applications.
It has an IP65 rating, providing protection against dust and water ingress for industrial environments.
The operating temperature range is from -25°C to +70°C, making it versatile for different applications.
The maximum switching frequency is 3.3 Hz, which supports effective detection in various scenarios.
The housing has a length of 94 mm and a width of 36 mm, designed for compact mounting.
It uses a Connector-V15 terminal type, facilitating easy installation in various systems.
It includes temperature compensation, is insensitive to compressed air, and has short circuit and overload protection.
This sensor complies with EN 60974-5-2 standards, ensuring it meets industrial norms.
It is suitable for automation systems, manufacturing process control, material handling detection, and machinery safety monitoring.
The maximum switching current is 200 mA, allowing it to handle various load requirements.
