Block 2 Output 200 VA Chassis Mount Safety Isolating Transformer, 2 x 115 V ac, 230 V ac Primary, EN 61558-2-4, TIM 200

Name: Block 2 Output 200 VA Chassis Mount Safety Isolating Transformer, 2 x 115 V ac, 230 V ac Primary, EN 61558-2-4, TIM 200
Brand: Block
SKU: 117321
Price: 175.74 USD
Availability: InStock



Category Chassis Mount Transformer Brand Block Condition New

Specifications

Country of Origin	Germany
Brand	Block
Length	223mm
Model	TIM 200
Depth	223mm
Gross Weight	3.6kg
Width	117mm
Construction	Class 2
Series	TIM 200
Maximum Operating Temperature	40°C
Number of outputs	2
Fixing Hole Diameter	4.3mm
Primary Voltage	230 V ac
Secondary Voltage	2 x 115 V ac
Minimum Operating Frequency	50Hz
Maximum Operating Frequency	60Hz
Protection Index	IP20
Insulation Category	Class B (Typical)
Max ambient temp	+40°C

Key Features

Short-circuit proof with thermal overload protection.
Dual independent secondary outputs configurable in series or parallel.
Encapsulated in plastic housing with IP20 protection.
High efficiency of approximately 88% for energy savings.
Mounting holes for secure chassis installation.
Integrated primary fuse protection for enhanced safety.
Insulation category Class B and construction Class 2.
Complies with EN 61558-2-4 and VDE 0570 Part 2-4 safety standards.

Product Description

Block TIM 200 is a 2 Output 200 VA chassis mount safety isolating transformer with a primary voltage of 230 V ac and dual secondary outputs rated at 2 x 115 V ac. Designed and manufactured in Germany, it complies with international safety standards including EN 61558-2-4, VDE 0570 Part 2-4, and IEC 61558-2-4, ensuring reliable insulation and protection in industrial and commercial electrical applications.

This single-phase transformer is short-circuit proof and equipped with thermal overload protection, making it suitable for robust electrical isolation purposes. It features two independent secondary windings that can be connected in series or parallel according to installation needs, providing versatile output configurations.

The transformer is housed in a plastic enclosure rated IP20 protection, with dimensions measuring 223 mm in length, 117 mm in width, and 223 mm in depth, and weighs 3.6 kilograms, making it suitable for secure chassis mounting via 4.3 mm fixing holes. It delivers high efficiency around 88%, helping reduce energy losses during operation.

Additional protection includes integrated primary fuse protection and compliance with insulation class B (typical) and construction class 2, ensuring durability and safety under a maximum ambient temperature of 40°C.

This product is commonly used in industrial machines, power supplies, laboratory equipment, and HVAC systems requiring secure isolation and stable voltage transformation. It is tested for 100% electrical integrity and 5 kV flash test for insulation reliability.

Short-circuit proof with thermal overload protection. Dual secondary windings configurable in series or parallel. Plastic housing encapsulation with IP20 protection rating. High efficiency approximately 88% for reduced energy loss.

Mounting holes with 4.3 mm diameter for secure installation. Integrated primary fuse providing protection against overloads. Insulation category Class B and construction Class 2 compliance. Standards and approvals including EN 61558-2-4, VDE 0570 Part 2-4, DIN EN 61558-2-4, IEC 61558-2-4.

Maximum ambient operating temperature of 40°C. Dimensions of 223 mm (L) x 117 mm (W) x 223 mm (D) and weight 3.6 kg. Explore more Chassis Mount Transformers and power supply components at EnvMart for reliable electrical solutions.
