STMicroelectronics 5-Element Uni-Directional TVS Diode 100 W, 6-Pin SOT-323 ESDA6V1-5W6
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1mm |
| Length | 2.2mm |
| Model | ESDA6V1-5W6 |
| Width | 1.35mm |
| Mount Type | Surface |
| Series | ESDAxxxWx |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-323 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 6 |
| Number of Elements per Chip | 5 |
| Diode Configuration | Common Anode |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 6.1V |
| Maximum Reverse Stand-off Voltage Vwm | 3V |
| Peak Pulse Power Dissipation Pppm | 100W |
| Test Current It | 1mA |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Provides common anode diode configuration for reliable circuit protection.
- Operates with minimum breakdown voltage of 6.1 V and maximum reverse stand-off voltage of 3 V.
- Rated for peak pulse power dissipation of 100 W ensuring robust transient voltage protection.
- Compact surface mount SOT-323 package with dimensions 2.2 mm length, 1.35 mm width, and 1 mm height.
- Features 5 elements per chip for effective ESD protection in electronic circuits.
- Suitable for operating temperature range from -40°C to 125°C for diverse environments.
- Maximum reverse leakage current is low at 1 μA supporting energy-efficient designs.
- Test current is 1 mA for quality and performance assurance.
Product Description
The STMicroelectronics ESDA6V1-5W6 is a 5-element unidirectional transient voltage suppressor (TVS) diode designed to protect sensitive electronic components from voltage spikes induced by electrostatic discharge (ESD).
Featuring a common anode configuration within a compact 6-pin SOT-323 surface mount package, this diode supports a peak pulse power dissipation of up to 100 W, making it suitable for robust surge protection.
Its electrical specifications include a minimum breakdown voltage (Vbr) of 6.1 V and a maximum reverse stand-off voltage (Vwm) of 3 V, enabling stable operation within these rated voltages. The device exhibits a very low maximum reverse leakage current of 1 μA, ensuring minimal power loss.
The diode is constructed to operate reliably over a temperature range of -40°C to 125°C, making it suitable for diverse industrial and commercial electronics applications.
Key features include 5 elements integrated per chip, dedicated ESD protection capability, and a test current rating of 1 mA. The size dimensions of 2.2 mm length, 1.35 mm width, and 1 mm height facilitate compact circuit design.
Common anode diode configuration for stable performance. Unidirectional transient voltage suppression capacity with 100 W power dissipation. Surface mount SOT-323 package reduces PCB space requirements. Wide operating temperature range ensures versatility in industrial scenarios.
Integrated ESD protection safeguards critical components from electrostatic damage. Low leakage current supports energy efficient designs. 5 elements per chip enhance transient suppression reliability. Test current rating validates quality and durability.
No automotive standard approvals; intended for general commercial and industrial electronics. This TVS Diode is ideal for use in consumer electronics, industrial equipment, and communication devices where transient voltage protection is critical.
Discover this and other semiconductor protection devices in the Electronics & Electricals category at EnvMart to ensure your products have reliable and long-lasting protection solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation of the STMicroelectronics ESDA6V1-5W6 is rated at 100 W, providing robust transient voltage protection.
The minimum breakdown voltage (Vbr) for this diode is 6.1 V, ensuring stable operation within specified voltage limits.
The maximum reverse stand-off voltage (Vwm) is 3 V, which is critical for maintaining circuit integrity during operation.
The maximum reverse leakage current for this model is 1 μA, which supports energy-efficient designs by minimizing power loss.
This TVS diode is housed in a compact SOT-323 package with dimensions of 2.2 mm in length, 1.35 mm in width, and 1 mm in height.
The operating temperature range for the STMicroelectronics ESDA6V1-5W6 is from -40°C to 125°C, making it suitable for diverse environments.
This model features 5 elements per chip, enhancing its effectiveness in transient voltage suppression and ESD protection.
It utilizes a common anode configuration, which is designed for reliable circuit protection in electronic applications.
The test current rating for this diode is 1 mA, which ensures quality and performance assurance during operation.
No, this TVS diode does not have automotive standard approvals and is intended for general commercial and industrial electronics.
The direction type of the STMicroelectronics ESDA6V1-5W6 is uni-directional, providing targeted transient voltage suppression.
This model is designed for surface mounting, which helps to reduce PCB space requirements in circuit designs.
