STMicroelectronics 4-Element Uni-Directional TVS Diode 100 W, 6-Pin SOT-23 ESDA6V1-5SC6

STMicroelectronics ESDA6V1-5SC6 is a 4-element uni-directional TVS diode array engineered to provide transient voltage suppression for sensitive electronic components. Featuring a common anode diode configuration, this device offers efficient protection against electrostatic discharge (ESD) events and high energy surges, making it ideal for industrial, communication, automotive, and consumer electronics applications.

This TVS diode array supports a peak pulse power dissipation rating of 100 watts, ensuring reliable clamping during voltage spikes. Packaged in a compact 6-pin SOT-23 surface mount package with a length of 3.05 mm, width of 1.75 mm, and height of 1.3 mm, it occupies minimal PCB space while delivering high performance.

The diode is uni-directional with a minimum breakdown voltage (Vbr) of 6.1 V and a maximum reverse stand-off voltage (Vwm) of 3 V. It operates effectively across a wide temperature range from -40°C to 125°C, suitable for harsh environments. The device also features a low maximum reverse leakage current of 1 μA, which contributes to improved circuit precision and energy efficiency.

With 4 elements per chip and a test current of 1 mA, the ESDA6V1-5SC6 meets stringent ESD protection requirements and standards for electronic devices. Its surface mount design with 6 pins enables easy integration in compact and dense PCB layouts.

This product is not certified for automotive standards but is widely used in various electronic component protection scenarios including industrial control systems, communication devices, and consumer electronics.

Common anode configuration ensuring reliable transient voltage suppression. Uni-directional diode type suitable for surge protection in sensitive electronics. Peak pulse power dissipation rating of 100 watts for robust protection.

Compact SOT-23 surface mount package measuring 3.05mm length, 1.75mm width, and 1.3mm height. Wide operating temperature range from -40°C to 125°C for various environments. Features low maximum reverse leakage current of 1μA enhancing circuit safety.

Equipped with 4 elements per chip for efficient transient suppression. Test current specified as 1mA ensuring compliance and reliability. Designed for surface mount applications with 6 pins for easy PCB integration. For advanced semiconductor and power protection solutions, browse EnvMart’s range of STMicroelectronics TVS Diode Arrays and other Semiconductor components.
