| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 0.47mm |
| Length | 1mm |
| Model | BZX8850S-C2V2YL |
| Mount Type | Surface |
| Series | BZX8850S |
| Maximum Operating Temperature | 150°C |
| Working voltage range | nominal 1.8 V to 75 V |
| Package Type | DFN1006BD-2 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 365mW |
| Diode Configuration | Single |
| Test Current It | 50μA |
| Maximum Reverse Leakage Current | 4μA |
| Nominal Zener Voltage Vz | 2.2V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 600Ω |
| Typical Voltage Temperature Coefficient | -3.5mV/K |
Nexperia BZX8850S-C2V2YL Zener Diode delivers voltage regulation with a nominal voltage of 2.2 V and a power dissipation capacity of 365 mW in a compact DFN1006BD-2 package. This single element voltage regulator diode is designed for surface mounting applications and ideal for use in low current, portable, and battery-powered electronic devices.
The device features a ±5% zener voltage tolerance and operates efficiently with a low test current of 50 μA, minimizing power consumption while maintaining stable voltage regulation. Its two-pin configuration and side-wettable flanks in the plastic leadless package support ease of assembly and improved solder joint reliability. The diode is capable of withstanding an operating temperature range from -55°C to 150°C, ensuring robust performance in industrial, automotive, and consumer electronics applications.
The maximum reverse leakage current is limited to 4 μA, and the maximum Zener impedance is 600 Ω, both contributing to consistent device operation across varying conditions. The device meets AEC-Q101 automotive standards, indicating suitability for use in demanding automotive environments requiring high reliability.
This Zener diode's typical voltage temperature coefficient is -3.5 mV/K, stabilizing voltage output despite temperature fluctuations. The working voltage range is nominally 1.8 V to 75 V, making this diode versatile for various voltage regulation tasks.
These attributes make the BZX8850S-C2V2YL diode well suited for applications in industrial control systems, telecommunications, instrumentation, and consumer electronics where precise voltage regulation and reliability are critical.
Nominal 2.2 V Zener voltage with 5% tolerance. Maximum power dissipation of 365 mW. Compact DFN1006BD-2 surface mount package. Low test current (50 μA) for energy-efficient operation. Operating temperature range from -55°C to 150°C.
Low reverse leakage current of 4 μA. AEC-Q101 automotive standard compliance. Voltage temperature coefficient of -3.5 mV/K. Explore more semiconductor components and Zener Diodes in EnvMart’s extensive catalog for electronics and electrical industrial applications.
