Panasonic Shielded Wirewound Surface Mount Inductor Metal Composite Core 3.3μH ±20% 14.7A Idc ETQP5M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 5mm |
| Length | 10.7mm |
| Model | ETQP5M |
| Depth | 10mm |
| Packaging | Tape & Reel |
| Series | ETQP5M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 3.3μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 14.7A |
| Pin Count | 2 |
| Maximum DC Resistance | 7.81mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- High heat resistance and reliability with metal composite core construction.
- Shielded design reduces electromagnetic interference.
- Operating temperature up to 150°C for demanding environments.
- Low DC resistance of 7.81mΩ ensures efficient current handling.
- Complies with AEC-Q200 automotive standard for quality assurance.
- Package supplied in tape and reel format for automated assembly.
- Wirewound construction with high vibration resistance integral design.
- Suitable for noise filtering in electronic drive circuits requiring high temperature operation.
Product Description
Panasonic ETQP5M Shielded Wirewound Surface Mount Inductor featuring a metal composite core delivers high heat resistance and reliability, making it suitable for industrial and automotive electronic applications. This inductor supports operation at temperatures up to 150°C, ensuring stable performance in harsh environments.
The device offers an inductance of 3.3μH with an inductance tolerance of ±20% and supports a maximum DC current of 14.7 A with a low DC resistance of 7.81mΩ. Its shielded wirewound construction minimizes electromagnetic interference and provides high vibration resistance through an integral design.
The component meets the stringent AEC-Q200 automotive standard, qualifying it for high-reliability automotive systems and other demanding industrial requirements. It is supplied in a surface mount package with dimensions of 10.7mm length, 5mm height, and 10mm depth, and is available in tape and reel packaging to facilitate efficient mass production and automated assembly processes.
High heat resistance and metal composite core for reliable operation. Shielded construction to reduce noise interference. Wide operating temperature range from -40°C to 150°C. Compliance with automotive AEC-Q200 standard.
Compact surface mount package for PCB assembly. Low DC resistance enhances efficiency. Suitable for noise filtering in high temperature drive circuits. Inductance 3.3μH with ±20% tolerance. Maximum DC current rating of 14.7 A.
Maximum self-resonant frequency 100kHz.
This Panasonic ETQP5M inductor is an excellent choice for industrial, automotive, and electronic equipment applications demanding high reliability, temperature stability, and EMI suppression. Browse EnvMart’s Surface Mount Inductors category to find complementary components and accessories for your design projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 3.3μH with an inductance tolerance of ±20%.
It supports a maximum DC current of 14.7 A, ensuring efficient current handling in various applications.
This inductor operates within a temperature range of -40°C to 150°C, making it suitable for demanding environments.
The maximum DC resistance is 7.81mΩ, which contributes to its efficiency in electronic circuits.
It features a wirewound construction with a metal composite core, providing high reliability and heat resistance.
It is supplied in tape and reel format, facilitating efficient mass production and automated assembly processes.
The ETQP5M complies with the AEC-Q200 automotive standard, ensuring quality assurance for automotive applications.
The maximum self-resonant frequency is 100kHz, which is important for its performance in high-frequency applications.
The dimensions are 10.7mm in length, 5mm in height, and 10mm in depth, making it compact for surface mount applications.
The core material is metal composite, which contributes to its high heat resistance and reliability.
It is suitable for noise filtering in electronic drive circuits that require high temperature operation.
This inductor complies with RoHS standards, ensuring it meets environmental regulations.
