Panasonic Shielded Wirewound Surface Mount Inductor with Metal Composite Core 10 μH ±20 % 6 A Idc ETQP4M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 4.8mm |
| Length | 7.4mm |
| Model | ETQP4M |
| Depth | 7mm |
| Packaging | Tape & Reel |
| Series | ETQP4M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 10μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 6A |
| Pin Count | 2 |
| Maximum DC Resistance | 39.6mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a metal composite core for high heat resistance and reliability.
- Surface mount design suitable for compact PCB assemblies.
- Features shielded wirewound construction to reduce electromagnetic interference.
- Maximum operating temperature of up to 150°C for demanding applications.
- Complies with RoHS and automotive standard AEC-Q200.
- Offers low audible noise and excellent inductance stability.
- Packaging includes tape and reel for automated assembly processes.
Product Description
Panasonic ETQP4M shielded wirewound surface mount inductor with metal composite core delivers stable inductance of 10 μH with a tolerance of ±20 % and supports a maximum DC current of 6 A. Designed with a shielded wirewound construction, it provides high heat and vibration resistance, making it suitable for industrial, automotive, and electronic applications requiring reliable noise filtering and high temperature operation up to 150°C.
The surface mount package with a tape and reel format facilitates automated PCB assembly. The inductor's core material is a ferrous alloy providing excellent inductance stability and low audible noise characteristics. This component complies with RoHS standards and the automotive AEC-Q200 qualification ensuring suitability for demanding automotive electronics.
Key dimensional specifications include 7.4 mm length, 4.8 mm height, and 7 mm depth with a 2-pin count for easy mounting and integration into circuits. Its shielded construction effectively reduces electromagnetic interference to enhance circuit performance.
This inductor is ideal for applications such as power supply noise filtering, voltage regulation, and other high frequency electronic circuit requirements in industrial machinery, automotive electronics, and commercial electronics manufacturing.
Constructed with a metal composite core for high heat and vibration resistance. High inductance stability with a low audible noise profile. Meets RoHS and automotive AEC-Q200 standards. Surface mount package supports efficient PCB assembly with tape and reel packaging.
Tolerant to operating temperatures from -40°C to 150°C. Wirewound construction ensures reliable electrical performance. Maximum DC resistance of 39.6 mΩ for efficient current handling. Compact size suitable for space-constrained electronic designs.
Explore more high-quality Surface Mount Inductors and electronic components from reliable brands in the EnvMart industrial electronics category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 10 μH with a tolerance of ±20%.
It supports a maximum DC current of 6 A.
The dimensions are 7.4 mm in length, 4.8 mm in height, and 7 mm in depth.
The maximum operating temperature is up to 150°C.
Yes, it complies with RoHS and the automotive standard AEC-Q200.
The core material is a metal composite, which provides high heat resistance and reliability.
It features a shielded wirewound construction that reduces electromagnetic interference.
It is packaged in tape and reel format, facilitating automated PCB assembly.
The maximum DC resistance is 39.6 mΩ, allowing for efficient current handling.
It is suitable for applications such as power supply noise filtering and voltage regulation in industrial and automotive electronics.
The termination style is surface mount, which is suitable for compact PCB designs.
This model has a pin count of 2 for easy mounting and integration into circuits.
