Panasonic Shielded Wirewound Surface Mount Inductor with Metal Composite Core, 15μH ±20% Inductance, 4.5A Maximum DC ETQP4M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 4mm |
| Length | 8.5mm |
| Model | ETQP4M |
| Depth | 8mm |
| Packaging | Tape & Reel |
| Series | ETQP4M |
| Maximum Operating Temperature | 155°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 15μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 4.5A |
| Pin Count | 2 |
| Maximum DC Resistance | 60.5mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- The inductor uses a metal composite core for high heat resistance and reliability.
- Designed with a shielded construction to minimize electromagnetic interference.
- Features high vibration resistance through integral construction for durability in demanding applications.
- Suitable for operation up to 155°C including self heat dissipation.
- Low audible noise and stable inductance under high bias current conditions.
- Packaging is provided as tape and reel for automated assembly.
- Complies with RoHS standards and automotive standard AEC-Q200.
- Compact surface mount package with dimensions approximately 8.5 mm length, 8 mm depth, and 4 mm height.
Product Description
Panasonic ETQP4M shielded wirewound Surface Mount Inductor incorporates a metal composite core, delivering a nominal inductance of 15μH with a tolerance of ±20%. It is engineered for high reliability and heat resistance, making it highly suitable for electronic components requiring inductive filtering and energy storage in compact circuit designs.
This inductor features a shielded construction that effectively reduces electromagnetic interference, alongside integral construction technology providing excellent vibration resistance. Its usage range extends from -55°C to a maximum operating temperature of 155°C, sustaining performance even under self-generated thermal load and high bias currents up to 4.5 A DC.
The product's compact dimensions - 8.5 mm length, 8 mm depth, and 4 mm height - enable dense surface mount applications. Its termination style with 2 pins facilitates surface mount assembly processes. Panasonic's adherence to RoHS and AEC-Q200 automotive standards underscores its suitability for demanding industrial and automotive electronics.
Notable attributes include low audible noise and stable inductance over temperature and current variations, beneficial for noise filtering and power regulation circuits in industrial, automotive, and electronic manufacturing environments.
The inductor's metal composite core enhances thermal stability and magnetic performance. Shielding effectively minimizes electromagnetic interference in sensitive circuit areas. Integral construction ensures durability under vibration and mechanical stress.
Surface mount package supports modern automated PCB assembly techniques. Compliance with international standards guarantees quality and reliability.
Ideal applications include power supplies, automotive electronic systems, industrial instrumentation, and electronic filters where precision inductance and thermal robustness are vital.
Explore a wide range of inductors and other electronic components within the Electronics Components category on EnvMart for quality industrial solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ETQP4M inductor has a nominal inductance value of 15μH with a tolerance of ±20%.
This model can handle a maximum DC current of 4.5A.
The inductor has dimensions of approximately 8.5 mm in length, 8 mm in depth, and 4 mm in height.
It operates within a temperature range of -55°C to a maximum of 155°C.
The inductor uses a metal composite core, which enhances thermal stability and magnetic performance.
The termination style of the ETQP4M is surface mount with 2 pins, facilitating automated assembly.
It is packaged in tape and reel format for automated assembly processes.
The ETQP4M complies with RoHS standards and the automotive standard AEC-Q200.
The shielded construction effectively reduces electromagnetic interference, making it suitable for sensitive circuit areas.
It is suitable for use in power supplies, automotive electronic systems, industrial instrumentation, and electronic filters.
The maximum DC resistance of the ETQP4M is 60.5mΩ.
This inductor features a wirewound construction, which contributes to its reliability and performance.
