Panasonic Shielded Wirewound Surface Mount Inductor 1.5 μH ±20% 8.1 A Idc Metal Composite Core ETQP3M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 3mm |
| Length | 5.5mm |
| Model | ETQP3M |
| Depth | 5mm |
| Packaging | Tape & Reel |
| Series | ETQP3M |
| Maximum Operating Temperature | 155°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 1.5μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 8.1A |
| Pin Count | 2 |
| Maximum DC Resistance | 13.2mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Features a wirewound inductor construction providing high reliability.
- Shielded design reduces electromagnetic interference and noise.
- Supports operation temperatures from -55°C up to 155°C.
- Complies with automotive standard AEC-Q200 for high quality assurance.
- Compact surface mount package with dimensions 5.5 mm length, 5 mm depth, and 3 mm height.
- Maximum DC resistance of 13.2 mΩ ensures low power loss.
- Includes a metal composite magnetic core for improved performance.
- Supplied in tape and reel packaging for surface mount assembly.
Product Description
Panasonic ETQP3M is a high-performance shielded wirewound surface mount inductor featuring a metal composite core. It offers an inductance of 1.5 μH with a tolerance of ±20%, supporting a maximum DC current of 8.1 A. This inductor is designed for demanding industrial and automotive electronic applications requiring stable inductance and low noise.
The device operates reliably across a wide temperature range from -55°C to 155°C, meeting automotive standard AEC-Q200. Its shielded construction effectively reduces electromagnetic interference, making it suitable for noise-sensitive circuits. The inductance stability is enhanced by the use of a ferrous alloy magnetic core within a molded wirewound construction.
With compact dimensions of 5.5 mm length, 5 mm depth, and 3 mm height, the ETQP3M inductor is ideal for high-density surface mount PCB assemblies. Its low maximum DC resistance of 13.2 mΩ minimizes power loss to improve efficiency. The product is supplied in tape and reel packaging, facilitating automated PCB assembly processes.
Typical applications include power regulation circuits, noise filters, and automotive electronic systems requiring high thermal and mechanical reliability. The Panasonic ETQP3M series ensures consistent performance under high vibration and thermal stress environments.
Features a wirewound inductor construction providing high reliability. Shielded design reduces electromagnetic interference and noise. Supports operation temperatures from -55°C up to 155°C. Complies with automotive standard AEC-Q200 for high quality assurance.
Compact surface mount package with dimensions 5.5 mm length, 5 mm depth, and 3 mm height. Maximum DC resistance of 13.2 mΩ ensures low power loss. Includes a metal composite magnetic core for improved performance. Supplied in tape and reel packaging for surface mount assembly.
Explore the Panasonic product range and Surface Mount Inductors category on EnvMart for advanced electronic components suited for industrial, automotive, and commercial usages.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ETQP3M inductor has an inductance value of 1.5 μH with a tolerance of ±20%.
This model supports a maximum DC current of 8.1 A.
The inductor has compact dimensions of 5.5 mm in length, 5 mm in depth, and 3 mm in height.
It operates reliably across a temperature range from -55°C to 155°C.
The inductor features a metal composite core, which enhances its performance.
The shielded design effectively reduces electromagnetic interference and noise, making it suitable for noise-sensitive circuits.
The maximum DC resistance is 13.2 mΩ, which helps minimize power loss.
It is supplied in tape and reel packaging, facilitating automated surface mount assembly.
This model complies with the automotive standard AEC-Q200 for high quality assurance.
It features a wirewound inductor construction, providing high reliability.
Typical applications include power regulation circuits, noise filters, and automotive electronic systems.
The inductor complies with RoHS standards, ensuring it meets environmental regulations.
