Weidmüller LSF Series PCB Terminal Block, 5-Contact, 3.5 mm Pitch, 1 Row, Push-In Actuator Connection, 300V, 10A 1250390000

Weidmüller 1250390000 LSF Series PCB Terminal Block is engineered for demanding electronic component assembly environments requiring dependable, high-performance connectors. This 5-contact terminal block features a 3.5 mm pitch and a single-row layout tailored for fully automatic pick-and-place assembly with reflow soldering compatibility.

The push-in actuator mechanism enables quick and secure conductor insertion without the need for tools, enhancing assembly efficiency and reducing maintenance downtime. It supports electrical currents up to 10A at 300V, suitable for a variety of industrial and commercial electronic applications.

Its housing is constructed from fibreglass liquid crystal polymer, providing excellent mechanical strength, thermal stability, and electrical insulation properties required in industrial PCB assemblies. The block accommodates wire sizes ranging from 0.13 mm² (28 AWG) to 1.5 mm² (14 AWG), meeting flexible wiring requirements.

The compact dimensions (18.2 mm width and 10.5 mm depth) allow for dense packing on printed circuit boards, while clearly marked clamping points and push buttons facilitate error-free connections. Its black coloration and male connector gender complement standardized electronic component designs.

This IPC-compliant terminal block suits automated SMT manufacturing, including multi-layer PCB designs of up to 72 poles. It is ideal for use in electronics manufacturing, industrial automation, instrumentation, and other sectors where reliable PCB connections are essential.

Features a push-in actuator wire connection system for quick and tool-free installation. Supports a current rating up to 10A and voltage rating of 300V for robust electrical performance. Constructed with fibreglass liquid crystal polymer housing material providing excellent insulation and durability.

Compact 1-row design with 18.2 mm width and 10.5 mm depth for space-efficient PCB integration. Suitable for solid wires and wire-end ferrules from 0.13 mm² to 1.5 mm² (28 AWG to 14 AWG). Terminal block color is black with male connector gender and 180° orientation for versatile assembly.

Optimized pitch length facilitates automated SMT processes and is compatible with multi-layer designs up to 72 poles.

Choose Weidmüller LSF Series PCB Terminal Block 1250390000 for precision, durability, and efficiency in electronic component connections. Browse more electronic components and connectors in the EnvMart catalog for tailored industry solutions.
