KEMET R75 Film Capacitor ±5 % 470 nF 2 kV DC 700 V AC Through Hole R75UR34704040J

Free Delivery in India | Lowest Global Shipping Charges

KEMET R75 Film Capacitor ±5 % 470 nF 2 kV DC 700 V AC Through Hole R75UR34704040J

Name: KEMET R75 Film Capacitor ±5 % 470 nF 2 kV DC 700 V AC Through Hole R75UR34704040J
Brand: KEMET
SKU: 109644
Price: 6.23 USD
Availability: InStock



Category Film Capacitor Brand KEMET Condition New

Specifications

Country of Origin	India
Brand	KEMET
Height	37mm
Length	32mm
Model	R75UR34704040J
Packaging	Bag
Width	22mm
Mount Type	Through Hole
Series	R75
Maximum Operating Temperature	105°C
Tolerance	±5 %
Capacitance	470nF
Minimum Operating Temperature	-55°C
Dissipation Factor	0.05%
Lead Length	30mm
Standards/Approvals	IEC 60286-2, RoHS
Pin Count	2
Rated AC Voltage	700V ac
Rated DC Voltage	2kV dc
Lead Pitch	27.5mm
Lead Diameter	0.8mm
Automotive Standard	AEC-Q100

Key Features

Constructed with metallized polypropylene film providing self-healing properties.
Encapsulated in UL94V-0 compliant self-extinguishing material for safety.
Designed for radial mounting with 27.5 mm lead pitch and 30 mm lead length.
Operates in temperature range from -55°C to 105°C for industrial environments.
Applications include deflection circuits in televisions, electronic ballasts, and power factor correction.
Package supplied in bag form for ease of use and insertion into machinery.
Compliance with automotive standard AEC-Q100 and IEC 60286-2 RoHS regulations.
Pin diameter of 0.8 mm and precise dimensions of 32 mm length, 22 mm width, and 37 mm height enhance installation accuracy.

Product Description

KEMET R75UR34704040J Film Capacitor ±5 % 470 nF 2 kV DC 700 V AC Through Hole is engineered for high-frequency electronic circuits requiring reliable performance and durability. It features metallized polypropylene film construction with radial leads made of tinned wire, providing excellent self-healing capabilities that prevent failure due to voltage spikes.

This capacitor supports a wide voltage range, with a rated DC voltage of 2 kV and AC voltage of 700 V, suitable for demanding industrial and commercial electronics. The device is encapsulated in a flame-retardant UL94V-0 material to ensure operational safety in sensitive environments.

Typical applications include deflection circuits in televisions for S-correction, resonant capacitors in electronic ballasts and compact lamps, power factor correction in switched mode power supplies (SMPS), as well as timing and oscillator circuits. It is not suitable for across-the-line applications.

Its radial mounting style with a lead pitch of 27.5 mm and lead length of 30 mm simplifies installation and integration on through-hole PCB assemblies. The product operates reliably within a temperature range of -55°C to 105°C, making it compatible with a broad spectrum of operational conditions commonly found in industrial, laboratory, and consumer electronics.

Constructed of metallized polypropylene film with radial tinned wire leads. Rated voltage: 2 kV DC and 700 V AC for versatile usage. Encapsulated in UL94V-0 flame-retardant material ensuring safety. AEC-Q100 automotive standard compliance guarantees reliability.

Pin diameter 0.8 mm and lead pitch 27.5 mm for precise mounting. Operating temperature from -55°C to 105°C suitable for harsh conditions. Ideal for deflection circuits, electronic ballasts, SMPS, and timing applications.

Meets IEC 60286-2 and RoHS standards for quality and environmental safety.

Use this capacitor in various industrial electronics, laboratory equipment, telecommunications, medical devices, and consumer electronics where high-frequency stability and voltage tolerance are critical. It is provided in a bag packaging format, facilitating efficient assembly in automated manufacturing lines.
