Samtec TSW Series Straight Through Hole Pin Header, 3 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSW-103-25-T-S-RA
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-103-25-T-S-RA |
| Mount Type | Through Hole |
| Special Features | Many options fo |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Features a 2.54 mm pitch suitable for standard PCB layouts.
- Constructed with phosphor bronze contacts plated in gold for reliable conductivity.
- Housing material is glass filled polyester, offering durability and insulation.
- Designed for through-hole mounting with a vertical solder termination.
- Operates reliably within a temperature range of -55°C to 125°C.
- Rated for voltages up to 550V, suitable for various electronic applications.
- Unshrouded male contacts for easy board-to-board connections.
- Single row with 3 positions enables compact circuit designs.
Product Description
Samtec TSW-103-25-T-S-RA is a high-quality straight through-hole pin header designed for robust electronic connections on printed circuit boards. It features 3 male contacts arranged in a single row with a standard 2.54 mm pitch. The pins are fabricated from phosphor bronze and plated with gold, ensuring excellent electrical conductivity and corrosion resistance. This pin header is encapsulated in a glass filled polyester housing that provides mechanical strength and electrical insulation.
Engineered for standard through-hole mounting, this connector offers a vertical orientation with solder termination, allowing secure and reliable attachments on PCB assemblies. It is unshrouded, making it easy to interface with a wide range of board-to-board connectors in industrial, electronics manufacturing, and prototype development contexts.
Operating temperature ranges from -55°C to 125°C, ensuring stability in harsh environments. The pin header is rated for a voltage of up to 550V, making it suitable for diverse power and signal applications in industrial electronics, communication equipment, and instrumentation.
The compact three-position, single-row design aids in space-efficient PCB layouts and seamless integration in electronic devices. Its high-quality materials and plating enhance longevity and performance in demanding applications.
Features a 2.54 mm pitch suitable for standard PCB layouts. Constructed with phosphor bronze contacts plated in gold for reliable conductivity. Housing material is glass filled polyester, offering durability and insulation.
Designed for through-hole mounting with a vertical solder termination. Operates reliably within a temperature range of -55°C to 125°C. Rated for voltages up to 550V, suitable for various electronic applications. Unshrouded male contacts for easy board-to-board connections.
Single row with 3 positions enables compact circuit designs.
This Samtec TSW series pin header is ideal for electronics manufacturing, industrial control systems, and laboratory instrumentation where reliable, small form factor board-to-board connectivity is required. Explore more precision connectors in the PCB Headers category on EnvMart to fulfill diverse design needs.
Explore more products in our PCB Pin Header category.
