Samtec Pin Header Vertical Surface Mount, 72 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSM-136-01-T-SV

Samtec TSM-136-01-T-SV is a high-quality pin header designed for vertical surface mount applications, featuring 72 contacts spaced at a 2.54 mm pitch in a single row configuration. The connector utilizes a black liquid crystal polymer housing that offers robust mechanical stability and excellent thermal performance for demanding electronic environments. The phosphor bronze contacts ensure good conductivity and mechanical strength, enhanced by gold or tin plating for corrosion resistance and reliable soldering.

This unshrouded header is intended for board-to-board connections on printed circuit boards (PCBs) and is terminated by solder. Rated for a maximum operating voltage of 475 volts AC and an operating temperature range from -55 to 125 degrees Celsius, it is suitable for a wide range of industrial, electronic, and commercial applications where durable and reliable electrical connections are required.

With a vertical orientation and standard 2.54 mm pitch, this header facilitates efficient PCB layout and design compatibility. Its single row of 72 contacts provides ample connection points while maintaining a compact form factor.

Applications include industrial control systems, electronic manufacturing, communications equipment, and embedded systems requiring robust connector solutions. The use of high-quality materials and attention to performance parameters ensure long-term reliability in varied operating conditions.

Single row vertical pin header with 72 contacts for versatile PCB interfacing. Black liquid crystal polymer housing for enhanced mechanical and thermal properties. Phosphor bronze contacts with gold or tin plating for optimal electrical connection and corrosion resistance.

Surface mount solder termination designed to integrate with standard PCB assembly processes. Rated voltage 475 VAC and temperature range from -55°C to +125°C for demanding applications. Unshrouded design allows ease of use for testing and prototyping environments.

Widely used in industrial, commercial, and electronic component applications. This product is part of the broader category of PCB Pin Headers and is a trusted solution for integrating electronic components and ensuring stable board-to-board connections.

Explore more PCB Pin Headers and connectors on EnvMart to find the best fit for your electronic design and manufacturing needs.
