Samtec Right Angle Through Hole PCB Socket 50-Contact, 2 Row, 2.54 mm Pitch, 4.7 A Current Rating Solder SSW-125-02-F-D-RA

Samtec SSW-125-02-F-D-RA is a professional-grade right angle through hole PCB socket featuring 50 female contacts arranged in 2 rows with a 2.54 mm pitch. This connector is part of the Samtec SSW series, engineered for reliable board-to-board connections in electronic assemblies.

The socket housing is molded from black liquid crystal polymer material, providing outstanding mechanical strength, temperature resistance, and electrical insulation. The phosphor bronze contacts are gold plated to enhance conductivity and durability, making the socket ideal for moderate current carrying of 4.7 A per pin.

The termination style is conventional solder tail, optimized for through-hole mounting on printed circuit boards. This product offers a high voltage rating of 655 V and supports standard as well as low insertion force contacts, ensuring ease of use during manufacturing while maintaining robust performance.

Operating across a broad temperature range from -55°C to 125°C, the socket is suitable for industrial, electronic, and commercial equipment applications where environmental conditions may vary.

The right angle orientation of the connector supports compact designs and efficient usage of PCB real estate. Industry professionals will find this socket useful for applications requiring secure and reliable electrical connectors adhering to the SSW series standard.

Constructed with a black liquid crystal polymer housing for durability and high performance. Phosphor bronze contacts with gold plating ensure reliable conductivity and corrosion resistance. Supports a current rating of 4.7 A per contact, suitable for moderate power applications.

Standard solder tail termination for through-hole mounting on PCB. Voltage rating up to 655 V ensures safe and robust electrical insulation. Wide operating temperature range from -55°C to 125°C accommodates diverse environmental conditions.

Designed with standard and low insertion force contacts for ease of assembly. Connector orientation is right angle, supporting space-efficient board layouts. Compatible with board-to-board connector systems within the SSW series.

This Samtec PCB Socket is ideally suited for use in industrial equipment, electronics manufacturing, testing and measurement devices, communication equipment, and consumer electronics. Utilizing this connector ensures dependable electrical connections and prolonged service life in demanding settings.
