Samtec TSW Series Straight Through Hole Pin Header 96 Contacts, 2.54 mm Pitch, 3 Row, Unshrouded TSW-132-08-L-T

Samtec TSW-132-08-L-T is a premium series straight through hole pin header designed with 96 male contacts arranged in 3 rows and spaced with a 2.54 mm pitch. Its unshrouded design facilitates flexible connections in high-density PCB configurations.

The header features a robust glass filled polyester housing which provides mechanical stability and long-term reliability in electronic assemblies. The contacts are made from phosphor bronze and plated with gold to enhance conductivity and prevent corrosion.

Intended for through-hole mounting, this connector supports solder termination, ensuring secure and stable PCB connections. Its straight vertical orientation and 0.025 inch square post contact system optimize alignment and insertion.

It operates efficiently within a temperature range of -55°C to 125°C and withstands voltages up to 550 V, making it suitable for a broad range of industrial, commercial, and electronic applications including telecommunications, automation, and manufacturing.

Designed for board-to-board interfacing, the TSW series offers multiple standard pin counts and terminal length options, providing versatility for complex PCB designs requiring reliable electrical connections.

The pin header features unshrouded, male contacts. It utilizes gold-plated phosphor bronze contacts ensuring reliable conductivity. The housing is constructed from glass filled polyester for durability. Designed for through-hole solder termination on PCBs.

Operational temperature range from -55°C to 125°C supports diverse environments. Rated for voltage up to 550 V to ensure electrical safety. Pin orientation is straight vertical for easy mounting. The contact system uses 0.025 inch (0.635 mm) square posts.

Suitable for industrial and electronic applications demanding dependable electrical connections. Explore more PCB Headers and connectors on EnvMart for comprehensive electronic component solutions.
