Wurth Elektronik 351 Series Pluggable Terminal Block 6-Contact 5.08 mm Pitch 20A 300V 1 Row 691351500006

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 351 Series Pluggable Terminal Block 6-Contact 5.08 mm Pitch 20A 300V 1 Row 691351500006

Name: Wurth Elektronik 351 Series Pluggable Terminal Block 6-Contact 5.08 mm Pitch 20A 300V 1 Row 691351500006
Brand: Wurth Elektronik
SKU: 107862



Category Pluggable Terminal Blocks Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	300V ac
Brand	Wurth Elektronik
Colour	Green
Orientation	Straight
Current	20A
Length	30.48mm
Depth	15.1mm
Width	18.2mm
Housing Material	Polyamide
Series	351
Number of Rows	1
Pitch	5.08mm
Number of Contacts	6
Connector Gender	Male
Minimum Wire Size mm²	0.21mm²
Maximum Wire Size mm²	3.31mm²
Minimum Wire Size AWG	24AWG
Maximum Wire Size AWG	12AWG
Wire Connection Method	Cable Entry

Key Features

Features 6 contacts suitable for various wiring needs.
Maintains a 5.08 mm pitch for standard compatibility.
Constructed from green UL94-V0 Polyamide for durability and safety.
Supports wire sizes from 24 AWG (0.21 mm²) up to 12 AWG (3.31 mm²).
Designed with a straight orientation and cable entry connection method.
Rated for a maximum current of 20A and voltage of 300V AC.
Compact dimensions measuring 30.48 mm length, 18.2 mm width, and 15.1 mm depth.
Includes tin-plated phosphor bronze wire guards for corrosion resistance.

Product Description

Wurth Elektronik 691351500006 is a high-quality 351 Series Pluggable Terminal Block featuring 6 contacts and a 5.08 mm pitch, rated for 20A current and 300V AC voltage. This terminal block is engineered for efficient and reliable cable entry connections in electronic assemblies and power distribution systems.

Constructed using green UL94-V0 rated Polyamide (PA66), this component ensures excellent electrical insulation and flame resistance, suitable for industrial, laboratory, and manufacturing environments. The male connector gender and straight orientation facilitate straightforward installation and wiring.

Its compact size, measuring 30.48 mm in length, 18.2 mm in width, and 15.1 mm in depth, supports space-efficient circuit board layouts and system designs.

Wurth Elektronik's 351 series terminal blocks are equipped with tin-plated phosphor bronze wire guards to enhance conductivity while providing corrosion resistance, thereby increasing product longevity and safety.

Compatible with wire sizes ranging from 24 AWG (0.21 mm²) to 12 AWG (3.31 mm²), this terminal block supports a wide range of wiring applications and ensures secure cable retention with slot type M3 screws.

The terminal block is perfectly suited for use in industrial automation, control panels, electrical equipment, and general electronics where a reliable, detachable wiring solution is required.

Designed to meet practical and industry demands, this 351 series pluggable terminal block ensures ease of service and maintenance with its modular and pluggable system architecture.

Features 6 contacts suitable for various wiring needs. Maintains a 5.08 mm pitch for standard compatibility. Constructed from green UL94-V0 Polyamide for durability and safety. Supports wire sizes from 24 AWG (0.21 mm²) up to 12 AWG (3.31 mm²).

Designed with a straight orientation and cable entry connection method. Rated for a maximum current of 20A and voltage of 300V AC. Compact dimensions measuring 30.48 mm length, 18.2 mm width, and 15.1 mm depth. Includes tin-plated phosphor bronze wire guards for corrosion resistance.

One-row, 351 series pluggable terminal block, ideal for industrial applications. Manufactured in China with focus on high-quality terminal block standards. Explore similar high-performance Pluggable Terminal Blocks and connectors in the Electronics Components category at EnvMart for your industrial and electrical needs.
