Phoenix Contact MKDSN 1.5/ 3 HT BK Series PCB Terminal Block, 3-Contact, 5 mm Pitch, 1 Row, 200V, 13.5A Rated Current 1985852

Phoenix Contact 1985852 MKDSN 1.5/ 3 HT BK Series PCB Terminal Block is designed for robust and reliable connections in electronic assemblies. Rated for a current of 13.5A and voltage of 200V, this 3-contact terminal block features a 5 mm pitch in a single-row configuration, ideal for compact PCB designs.

The terminal block is manufactured using high-temperature resistant polyamide, providing excellent mechanical stability and durability under demanding operating conditions. The screw connection method secures wires firmly, allowing installation flexibility for wire sizes between 0.14 mm² (26 AWG) and 1.5 mm² (16 AWG).

The component's horizontal orientation facilitates efficient use of PCB space while enabling integration into automated reflow soldering processes. To ensure optimal performance and longevity, it is advised to pre-heat treat these components at +125°C for 48 hours before exposure to reflow oven conditions.

Compact dimensions of 15 mm width, 13.5 mm depth, and 8.1 mm length support the design of densely populated circuit boards without compromising reliability. The terminal uses screw connection ensuring strong and reliable wire fixing.

Polyamide housing provides excellent thermal and mechanical stability. Suitable for wire sizes ranging from 0.14 mm² to 1.5 mm² or 26 AWG to 16 AWG. Horizontal mounting orientation optimizes PCB layout and assembly. Designed with 3 contacts and a 5 mm pitch for precise spacing.

Black color housing enhances identification and assembly aesthetics. Recommended heat treatment prior to reflow soldering increases reliability.

This terminal block is commonly used in industrial electronics, automation panels, and manufacturing equipment, supporting secure electrical connections in demanding environments. It enables engineers and designers to populate PCBs efficiently, ensuring high mechanical stability and electrical performance.

Explore a wide range of Phoenix Contact products and other high-quality PCB Terminal Blocks at EnvMart for your industrial and electronic assembly requirements.
