TRACOPOWER High Efficiency Through Hole Switching Regulator 15V DC Output, 500mA Output Current TSR 0.5-24150
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | TRACOPOWER |
| Efficiency | 97% |
| Length | 11.5mm |
| Model | TSR 0.5-24150 |
| Depth | 10.2mm |
| Gross Weight | 2g |
| Width | 7.55mm |
| Mount Type | Through Hole |
| Series | TSR 0.5 |
| Output Current | 500mA |
| Maximum Operating Temperature | 90°C |
| Package Type | SIP-3 |
| Load Regulation | ±0.4 % |
| Minimum Operating Temperature | -40°C |
| MTBF | 2000000h |
| Number of outputs | 1 |
| Ripple and Noise | 40mV Pk-Pk |
| Maximum Input Voltage | 32V dc |
| Line Regulation | ±0.2 % |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 18V |
| Output Voltage 1 | 15V dc |
Key Features
- Compact SIP-3 package design.
- High efficiency up to 97%.
- Wide operating temperature range from -40°C to 90°C.
- Features over-temperature and short circuit protection.
- Low standby current reduces power consumption.
- No external capacitors required for stable operation.
- Accurate output voltage regulation with ±0.2% line and ±0.4% load regulation.
- Remote On/Off input for flexible control.
Product Description
TRACOPOWER TSR 0.5-24150 is a high-efficiency through hole switching regulator delivering 15V DC output at 500mA current. It is designed as a drop-in replacement for traditional linear regulators, offering up to 97% efficiency and reducing power loss significantly. The compact SIP-3 package measures 11.5mm in length, 7.55mm in width, and 10.2mm in depth, making it suitable for compact PCB layouts.
This switching regulator operates reliably in harsh environments with a temperature range from -40°C minimum to 90°C maximum. It includes built-in over-temperature and short circuit protection to safeguard against fault conditions. The low standby current and excellent load and line regulation (±0.4% and ±0.2%, respectively) provide consistent and reliable voltage output for sensitive electronic circuits.
The TSR 0.5 series does not require external capacitors, simplifying board design and enhancing robustness. The device supports a remote On/Off function for remote enablement or shutdown, beneficial in battery-powered applications. With a maximum input voltage of 32V DC and a minimum input of 18V DC, it is versatile for various power supply conditions.
Its high Mean Time Between Failure (MTBF) of 2,000,000 hours underscores its durability for industrial and commercial usage. This regulator is RoHS compliant and manufactured in Taiwan, Province Of China, ensuring quality and environmental standards compliance.
Compact SIP-3 package design. Efficient operation with up to 97% efficiency. Wide temperature range from -40°C to 90°C. Integrated safety features including over-temperature and short circuit protection. Low standby power consumption.
Accurate line and load voltage regulation. No external capacitors required. Remote On/Off input capability. Designed for replacement of LM78 linear regulators. High reliability and long MTBF.
This TRACOPOWER Switching Regulator is ideal for electronic, industrial, and laboratory power supply applications requiring efficient and stable DC voltage conversion. For additional TRACOPOWER power solutions, continue browsing related products on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model delivers a stable output voltage of 15V DC.
The maximum output current for this unit is 500mA.
It has an efficiency rating of up to 97%.
The package measures 11.5mm in length, 7.55mm in width, and 10.2mm in depth.
This switching regulator operates within a temperature range of -40°C to 90°C.
No, it does not require external capacitors for stable operation.
The line regulation is ±0.2% and the load regulation is ±0.4%.
It includes over-temperature and short circuit protection.
The maximum input voltage is 32V DC.
The minimum input voltage is 18V DC.
The MTBF is rated at 2,000,000 hours.
Yes, this switching regulator is RoHS compliant.
