Panasonic Surface Mount Inductor Metal Composite Core 3.3 μH ±20% 8.6 A IDC 0530 Package ETQP3M
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 3mm |
| Length | 5.5mm |
| Model | ETQP3M |
| Depth | 5mm |
| Packaging | Box |
| Series | ETQP3M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 3.3μH |
| Standards/Approvals | RoHS |
| Package/Case | 0530 |
| Maximum DC Current | 8.6A |
| Maximum DC Resistance | 34.4mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Features a metal composite core for improved stability and low noise.
- Wirewound construction ensures high reliability and stable inductance.
- Designed for high temperature operation up to 150°C.
- Complies with automotive AEC-Q200 standard for rigorous testing.
- Maximum DC resistance is 34.4 mΩ, enabling low power loss.
- Suitable for DC-DC converters and noise filters in automotive electronics.
- Compact 0530 package with dimensions 5.5mm length, 3mm height, and 5mm depth.
- RoHS compliant and molded for robust long-term durability.
Product Description
Panasonic ETQP3M Surface Mount Inductor features a metal composite core with an inductance value of 3.3 μH ±20%. It supports a maximum DC current of 8.6 A and is designed to operate reliably at temperatures ranging from -40°C to 150°C, making it highly suitable for demanding industrial and automotive environments.
This wirewound inductor with package size 0530 measures 5.5 mm in length, 3 mm in height, and 5 mm in depth. The metal composite core technology reduces buzz noise and improves efficiency by minimizing eddy-current losses. The product is RoHS compliant and molded for stable performance and vibration resistance.
Product series ETQP3M is AEC-Q200 qualified, ensuring high reliability conforming to automotive standards. Its low DC resistance of 34.4 mΩ provides efficient power handling, making it ideal for applications such as DC-DC converters and noise filtering in drive circuitry requiring high peak currents and temperature endurance.
Features a metal composite core for improved stability and low noise. Wirewound construction ensures high reliability and stable inductance. Designed for high temperature operation up to 150°C. Complies with automotive AEC-Q200 standard for rigorous testing.
Maximum DC resistance is 34.4 mΩ, enabling low power loss. Suitable for DC-DC converters and noise filters in automotive electronics. Compact 0530 package with dimensions 5.5mm length, 3mm height, and 5mm depth. RoHS compliant and molded for robust long-term durability.
This inductor is an excellent choice for industrial, automotive, and electronic manufacturing applications requiring durable and high-performance surface mount components. Browse the full range of Panasonic electronic components and Surface Mount Inductors at EnvMart for reliable solutions in your projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 3.3 μH with a tolerance of ±20%.
This inductor supports a maximum DC current of 8.6 A.
The dimensions of the 0530 package are 5.5 mm in length, 3 mm in height, and 5 mm in depth.
The maximum operating temperature for this model is 150°C.
Yes, it complies with the RoHS standard and is AEC-Q200 qualified for automotive applications.
It features a metal composite core, which helps improve stability and reduce noise.
The maximum DC resistance is 34.4 mΩ, which enables low power loss.
This inductor utilizes a wirewound construction for high reliability and stable inductance.
It is suitable for use in DC-DC converters and noise filters in automotive electronics.
The minimum operating temperature is -40°C, making it suitable for a wide range of environments.
The maximum self-resonant frequency is 100 kHz.
The inductor is packaged in a box.
