Samtec Pin Header 8 Contacts 2.54 mm Pitch 2 Row Through Hole Unshrouded Gold Plating 550V TSW-104-08-F-D-RA
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-104-08-F-D-RA |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Operating temp range | -55 °C to +125 °C with Gold -55 °C to +105 °C with Tin |
| Plating used | Au or Sn over 50 μ" (1.27 μm) Ni |
Key Features
- The housing is made of durable black glass filled polyester for insulation.
- Contacts are phosphor bronze with high-quality gold plating for excellent conductivity.
- Designed for through-hole mounting with unshrouded connectors for ease of soldering.
- Operates reliably between -55°C and 125°C with gold plating ensuring extended temperature range.
- Compatible with Samtec SSW, BCS, ESQ, and CES series connectors.
- Ideal for industrial, electronic manufacturing, PCB assembly, and prototyping environments.
- RoHS compliant offering eco-friendly, lead-free design.
Product Description
Samtec TSW-104-08-F-D-RA is a precision-engineered PCB Pin Header featuring 8 male contacts arranged in 2 rows with a 2.54 mm pitch. The connector housing is manufactured from robust black glass filled polyester, providing reliable electrical insulation and mechanical strength in electronic assemblies.
The contact pins are made of phosphor bronze with a gold or tin plating of over 50 μ" (1.27 μm) nickel, ensuring excellent conductivity, resistance to corrosion, and durability. This unshrouded, through-hole connector is designed for straightforward solder termination on printed circuit boards.
Operating temperature ranges from -55°C to 125°C with gold plating, supporting usage in harsh industrial and manufacturing environments. With a voltage rating up to 550 VAC mated with compatible Samtec connectors, it meets demanding electrical performance criteria.
This connector is widely used in electronics assembly lines, prototyping, industrial automation hardware, and PCB manufacturing. Its unshrouded design makes it adaptable to various layout configurations while maintaining reliable signal integrity.
The durable glass filled polyester housing provides mechanical stability and insulation. Phosphor bronze contacts with gold plating deliver superior electrical performance. Compatible with a range of Samtec connector series for flexible board-to-board solutions.
Designed for through-hole mounting ensuring firm mechanical connection. Supports extended temperature ranges meeting industrial standards. RoHS compliant ensuring environmentally responsible manufacturing. Typical applications include electronics manufacturing, industrial controls, and prototyping.
Explore our extensive selection of PCB headers at EnvMart for reliable electronic component sourcing and enhanced manufacturing productivity.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pin header has a voltage rating of 550 VAC when mated with compatible connectors.
This model features a contact pitch of 2.54 mm.
The housing is made from glass filled polyester, while the contacts are made of phosphor bronze with gold plating.
It operates reliably between -55°C and 125°C when gold plated, and up to 105°C with tin plating.
This connector has a total of 8 male contacts arranged in 2 rows.
Yes, it is specifically designed for through-hole mounting, ensuring a firm mechanical connection.
This model utilizes solder termination for connecting to printed circuit boards.
It is compatible with Samtec SSW, BCS, ESQ, and CES series connectors.
The contacts are plated with gold or tin over 50 μ" (1.27 μm) nickel, providing excellent conductivity.
It is suitable for use in industrial automation, electronics manufacturing, PCB assembly, and prototyping environments.
The contacts in this model are oriented straight.
The country of origin for this pin header is India.
