Samtec TSW Series Straight Through Hole Pin Header, 2 Contact 2 Row 2.54 mm Pitch, Unshrouded TSW-101-07-F-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-101-07-F-D |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Operating temp range | -55 °C to +125 °C with Gold -55 °C to +105 °C with Tin |
| Plating used | Au or Sn over 50 μ" (1.27 μm) Ni |
Key Features
- Constructed with glass filled polyester housing for durability.
- Phosphor bronze contact material with gold plating for reliable conductivity.
- Supports voltage rating up to 550V suitable for board-to-board connections.
- Operates within temperature range from -55°C to 125°C ensuring wide environmental compatibility.
- Designed for through-hole solder termination providing strong mechanical and electrical connection.
- Unshrouded design allows easy mate and inspection of pins.
- Complies with RoHS standards for environmental safety.
- Ideal for electronic component applications requiring compact pin headers.
Product Description
It is designed with 2 contacts arranged in 2 rows at 2.54 mm pitch spacing, making it suitable for compact PCB interconnections.
The housing is made of black glass filled polyester which offers strong insulation and mechanical stability. The contacts are fabricated from phosphor bronze and plated with gold plating over nickel, which ensures excellent electrical conductivity and corrosion resistance.
This pin header supports a high voltage rating up to 550 volts, making it ideal for various board-to-board connector applications in industrial, electronic manufacturing, and test equipment.
It operates reliably within a temperature range from -55 °C to +125 °C, with solder termination suitable for through-hole mounting techniques which provide sturdy mechanical and electrical connections on printed circuit boards.
The unshrouded pin design enables easy connection and disconnection during assembly or maintenance while ensuring accessibility for inspection or repair. This product is RoHS compliant, assuring environmentally responsible manufacturing.
Constructed with glass filled polyester housing for durability. Phosphor bronze contact material with gold plating for reliable conductivity. Supports voltage rating up to 550V suitable for board-to-board connections. Operates within temperature range from -55°C to 125°C ensuring wide environmental compatibility.
Designed for through-hole solder termination providing strong mechanical and electrical connection. Unshrouded design allows easy mate and inspection of pins. Complies with RoHS standards for environmental safety. Ideal for electronic component applications requiring compact pin headers.
This pin header is extensively used in electronics manufacturing, industrial automation, communication equipment, and testing laboratories for reliable PCB connector solutions. The Samtec brand is known for its high-precision and quality electronic interconnect products.
Explore more Samtec PCB Headers and connectors on EnvMart for your industrial and laboratory electronics needs.
