Hirose DF9 Series Straight Surface PCB Socket, 9-Contact, 2 Row, 1 mm Pitch, 150V, 500mA, Solder Termination DF9-9S-1V(32)
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 150V |
| Brand | Hirose |
| Orientation | Straight |
| Current | 500mA |
| Model | DF9-9S-1V(32) |
| Mount Type | Surface |
| Housing Material | Polyamide |
| Contact Material | Copper |
| Series | DF9 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -45°C |
| Number of Rows | 2 |
| Pitch | 1mm |
| Contact Plating | Tin |
| Number of Contacts | 9 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Complies with the VESA FPDI-1 standard interface for LCD displays.
- Features a trapezoidal shaped mating interface to prevent misinsertion.
- Includes an easy lock mechanism that ensures secure connector mating with tactile confirmation.
- Constructed with polyamide housing and copper contacts plated with tin.
- Mount type is surface mount technology (SMT) with straight orientation.
- Operates reliably within temperature ranges from -45°C to 125°C.
- Designed for board-to-board connector systems.
- Suitable for use in portable devices, POS terminals, and handheld measurement instruments.
Product Description
Hirose DF9-9S-1V(32) is a high-quality PCB socket connector from the DF9 Series featuring a straight surface mount design with 9 contacts arranged in 2 rows at a 1 mm pitch. This connector conforms to the VESA FPDI-1 standard interface used for LCD displays, providing reliable mechanical and electrical performance in compact form factors.
The trapezoidal shaped mating interface effectively prevents misinsertion, while the easy lock mechanism offers a secure connection with tactile feedback that confirms proper engagement.
The housing is made of durable polyamide material, and the contacts are crafted from copper with tin plating to ensure excellent conductivity and corrosion resistance.
Operating voltage is 150V with a current rating of 500mA, suitable for a variety of low-power board-to-board applications. The socket is designed with surface mount technology and oriented straight to facilitate PCB assembly.
This PCB socket operates reliably within an extended temperature range from -45°C to 125°C, making it suitable for harsh environmental conditions.
Its construction includes mounting bosses to hold connectors securely during soldering or manual placement, and SMT versions have metal fittings to prevent solder joint peeling due to mechanical stress.
Complies with VESA FPDI-1 standard for LCD interfaces. Trapezoidal mating shape prevents misinsertion. Easy lock tactile mechanism for secure mating. Polyamide housing and copper contacts with tin plating. Surface mount, straight orientation, 1 mm pitch.
Operating temperature range: -45°C to 125°C. Rated for 150V and 500mA current. Ideal for portable equipment and handheld devices. Metal fittings prevent solder joint damage in SMT versions. This product is widely used in industrial electronics applications, including LCD modules, portable measurement instruments, and point-of-sale terminals.
Explore more PCB Sockets and connectors on EnvMart for reliable and precise electronic component solutions.
