Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 33 μH ±20% 6.22 A Idc DR127-330-R
Specifications
| Country of Origin | China |
|---|---|
| Brand | Eaton |
| Height | 8mm |
| Length | 12.5mm |
| Model | DR127-330-R |
| Depth | 12.5mm |
| Packaging | Reel |
| Series | DR |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 33μH |
| Standards/Approvals | RoHS |
| Package/Case | 0127 |
| Maximum DC Current | 6.22A |
| Pin Count | 2 |
| Maximum DC Resistance | 60mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
Key Features
- The inductor features a ferrite core construction ensuring efficient magnetic shielding.
- Designed for surface mount applications with a compact 0127 package.
- Operates reliably within a temperature range from -40°C to 125°C.
- Maximum DC resistance is 60 milliohms, optimizing performance in DC-DC converters.
- Mounting reel packaging facilitates automated machine insertion.
- Maximum self-resonant frequency is 100 kHz, suitable for noise filtering and power management.
- Construction is wirewound and moulded for durability and stability.
- Complies with RoHS standards ensuring environmental safety.
Product Description
Eaton DR127-330-R shielded wirewound surface mount inductor with a ferrite core offers 33 microhenry inductance with ±20% tolerance and 6.22 ampere maximum DC current capacity. It is specifically designed for surface mount technology (SMT) applications requiring compact, magnetically shielded inductors.
This inductor features a robust ferrite core which minimizes electromagnetic interference, making it ideal for sensitive electronic equipment such as computers, DVD players, portable devices, and LCD panels. The durable wirewound construction ensures high efficiency and stable operation at elevated temperatures up to 125°C.
Its small 0127 package with dimensions of 12.5 mm length and 8 mm height enables integration into compact PCB layouts. The device has a low maximum DC resistance of 60 milliohms, reducing power loss in demanding power conversion circuits including buck, boost, forward, and resonant converters.
Designed to operate over a minimum temperature of -40°C, the inductor supports applications in harsh environmental conditions. The maximum self-resonant frequency of 100 kHz and moulded construction make this component suitable for noise filtering and choke functions in electronic circuits.
The product is compliant with RoHS directives, assuring reduced hazardous substances. It is supplied on a reel packaging suited for automated manufacturing processes, streamlining assembly efficiency.
The inductor's ferrite core design provides magnetic shielding for reduced interference. Wirewound construction offers excellent efficiency and stability. Surface mount 0127 package measures 12.5 mm depth and 8 mm height.
Maximum DC current rating of 6.22 A with a low resistance of 60 mΩ. Wide operating temperature range from -40°C to 125°C for versatile use. Maximum self-resonant frequency of 100 kHz supports filtering applications. RoHS compliant, ensuring environmentally friendly manufacturing.
Supplied on reel packaging compatible with automated insertion machinery.
This Eaton DR127-330-R inductor is ideal for industrial electronic manufacturing, power supply regulation, telecommunications, and consumer electronics requiring reliable surface mount inductors with magnetic shielding. Browse more in the Surface Mount Inductors category on EnvMart to find compatible components and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 33 microhenries (μH) with a tolerance of ±20%.
The maximum DC current capacity of this inductor is 6.22 amperes (A).
It has a maximum DC resistance of 60 milliohms (mΩ), which helps optimize performance in power circuits.
This unit operates reliably within a temperature range from -40°C to 125°C.
The maximum self-resonant frequency of this inductor is 100 kHz, making it suitable for noise filtering applications.
The inductor is housed in a compact 0127 package, measuring 12.5 mm in length and 8 mm in height.
It features a ferrite core construction, which provides efficient magnetic shielding.
It is supplied on a reel, which facilitates automated machine insertion during assembly.
This model utilizes a surface mount termination style, suitable for SMT applications.
Yes, it complies with RoHS standards, ensuring reduced hazardous substances in its manufacturing.
This inductor is ideal for applications in power supply regulation, telecommunications, and consumer electronics.
It features a wirewound construction, which contributes to its efficiency and stability in operation.
