Crydom Solid State Relay, 40 A Load Current, Panel Mount, 150 V DC Load, 32 V DC Control DC200D40C

The Crydom DC200D40C is a high-performance Solid State Relay designed for industrial automation and electrical control applications. It supports a maximum load current of 40 A and can handle DC load voltages up to 150 V, making it suitable for medium to high power DC switching tasks. This relay features panel mount installation compatibility, designed with screw terminals to ensure secure and reliable electrical connections.

Its optically isolated MOSFET output and zero voltage switching function contribute to reduced electrical noise and enhanced sensitivity. The device operates within a control voltage range from 4 V DC to 32 V DC, facilitating broad compatibility with control systems.

The product's compact dimensions (58.2 mm length, 22 mm width, 32.9 mm height) allow easy integration into control panels with space constraints. It is rated for IP20 protection with an optional cover, providing safety against accidental contact. The relay can function reliably across a wide temperature range from -40°C to 80°C, suitable for harsh industrial environments.

Electrical characteristics include minimal off state leakage current of 0.2 mA, an 8 pF capacitance level, and the use of SCR output type optimized for DC switching applications. Safety and environmental compliance are supported with certifications such as CE and RoHS, highlighting its quality and adherence to international standards.

Typical applications include industrial automation control systems, equipment switching, process control setups, and other environments requiring reliable and noise-free DC switching. The integral LED indicator enhances user feedback on operational status, improving maintenance and troubleshooting efficiency.

This relay is manufactured in Mexico adhering to high-quality manufacturing standards. The product is part of Crydom's PowerPlus DC series, known for optically isolated outputs, ease of parallel operation for higher current requirements, and robustness in demanding applications.

This Solid State Relay supports a maximum load current of 40 A. Designed for panel mount installation with screw terminal type for secure connections. Operates with a control voltage range of 4 V DC minimum to 32 V DC maximum.

Provides zero voltage switching function to reduce electrical noise in switching applications. Build supports a maximum operating temperature of 80°C and a minimum temperature of -40°C. Compact dimensions: length 58.2 mm, width 22 mm, height 32.9 mm.

Off state leakage current is minimal at 0.2 mA ensuring low power loss. Capacitance specified at 8 pF and output type uses SCR for robust DC switching. Includes an LED status indicator and optional IP20 cover for protection.

Manufactured in Mexico, meeting CE and RoHS standards. Explore our extensive Crydom product range and related industrial automation components at EnvMart for reliable and quality electrical control solutions.
