Winslow Straight Through Hole Mount 2.54 mm Pitch IC Socket Adapter, QFN to PGA WA13099DQAETRC
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Winslow |
| Orientation | Straight |
| Model | WA13099DQAETRC |
| Mount Type | Through Hole |
| Housing Material | Fibreglass |
| Contact Material | Brass |
| Pitch | 2.54mm |
| Connection Gender A | Female |
| Number of Contacts A | 28 |
| Connection Gender B | Male |
| Connection A | QFN |
| Connection B | PGA |
Key Features
- Allows conversion between QFN and PGA package styles.
- Features 28 female contacts on QFN side and 28 male contacts on PGA side.
- Contact material is brass with fibreglass housing for reliability.
- Straight orientation supports through-hole mounting.
- Designed for electronic component interface applications.
- Manufactured in the United Kingdom ensuring quality standards.
Product Description
Winslow WA13099DQAETRC Straight Through Hole Mount IC Socket Adapter features a 2.54 mm pitch, designed to convert Quad-Flat No-Leads (QFN) packages to Pin Grid Array (PGA) format for easy PCB integration.
This IC socket adapter contains 28 female connection contacts on the QFN side and 28 male contacts on the PGA side, facilitating reliable electrical connections for development or prototyping purposes. The contacts are made from brass, ensuring good conductivity and durability, while the fibreglass housing provides structural integrity and resistance to environmental factors.
The adapter is mounted using a through-hole technique with a straight orientation which simplifies PCB board layout and assembly processes. This Adapter is part of the 'Adaptics' range by Winslow, which helps reduce development costs by allowing easy package style conversions without redesigning boards.
Allows conversion between QFN and PGA package styles. Features 28 female contacts on QFN side and 28 male contacts on PGA side. Contact material is brass with fibreglass housing for reliability. Straight orientation supports through-hole mounting.
Manufactured in the United Kingdom ensuring quality standards.
This socket adapter is ideal for industrial electronic manufacturing, laboratory development setups, prototype board designs, and other scenarios requiring versatile IC package interfacing.
Explore more IC Socket Adapters and related electronic components at EnvMart to find solutions tailored to your technical requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of the Winslow WA13099DQAETRC IC socket adapter is 2.54 mm.
This adapter features 28 female contacts on the QFN side and 28 male contacts on the PGA side.
The contacts are made from brass, and the housing is constructed from fibreglass.
It supports through-hole mounting with a straight orientation.
The QFN side has female connections, while the PGA side has male connections.
This adapter is manufactured in the United Kingdom.
It is suitable for industrial electronic manufacturing, laboratory development setups, and prototype board designs.
The model number of this socket adapter is WA13099DQAETRC.
It is designed to convert QFN packages to PGA format for easy PCB integration.
Yes, it is part of the 'Adaptics' range by Winslow.
The straight orientation simplifies PCB board layout and assembly processes.
The brass contacts ensure good conductivity and durability for reliable electrical connections.
