KEMET Film Capacitor, 2.7 nF, ±5 % Tolerance, 2 kV DC, 700 V AC, Through Hole Mount R76UI127050H4J

KEMET R76UI127050H4J Film Capacitor is a high-quality electronic component with a nominal capacitance of 2.7 nF and a tolerance of ±5 %. It is rated for a maximum DC voltage of 2 kV and AC voltage of 700 V, making it suitable for demanding applications requiring stable and reliable capacitance under high voltage stresses.

This capacitor utilizes polypropylene film and double metallized polyester film electrodes to ensure durability, low losses, and excellent electrical performance. The radial tinned wire leads are designed for through hole mounting, with a pitch of 15 mm and a lead length of 25 mm, providing ease of PCB assembly.

The device is encapsulated in a self-extinguishing solvent resistant plastic case with thermosetting resin, providing protection against environmental factors. It operates efficiently over a temperature range of −55°C to +125°C and meets international standards IEC 60286-2 and RoHS compliance, guaranteeing environmental and safety requisites.

Commonly used in industrial and commercial electronic equipment, this capacitor is ideal for resonant circuits, high-frequency current handling, snubber circuits, and commutation circuits involving silicon-controlled rectifiers (SCR), IGBTs, and SiC MOSFETs. Its lead-free solder terminations comply with automotive grade AEC-Q200, further expanding its application in automotive and harsh environment electronics.

Constructed of polypropylene film and double metallized polyester film electrodes. Radial leads of tinned wire, welded to capacitor winding ends. Self-extinguishing solvent resistant plastic encapsulation. Rated for 2 kV DC and 700 V AC voltages.

Operating temperature range: −55°C to +125°C. Lead pitch: 15 mm with solderable leads. Complies with IEC 60286-2, RoHS, and automotive AEC-Q200 standards. Suitable for high frequency, snubber, SCR, IGBT, and SiC commutation circuits.

Lead-free terminations compliant with automotive requirements. This film capacitor is manufactured in China and supplied in bags, ensuring easy handling and transportation.

For additional technical documentation, designs, and certifications, users can consult KEMET's official resources and standards. This product enhances reliability and performance in a broad spectrum of high voltage and temperature environments.
