STMicroelectronics 1-Element Bi-Directional TVS Diode 600 W, Surface Mount DO-214 Package SMBJ6.5CA-TR

STMicroelectronics SMBJ6.5CA-TR is a high-power 1-element bi-directional transient voltage suppressor (TVS) diode designed to protect sensitive electronic circuits from voltage spikes and transient surges. Rated at a peak pulse power dissipation of 600 W, it supports robust protection mechanisms in various industrial and electronic applications.

This diode operates bi-directionally and features a single diode configuration housed in a compact, surface mount DO-214 package, making it suitable for automated PCB assembly. Its low leakage current of 20 μA ensures minimal power consumption while maintaining excellent surge absorption capabilities.

With a minimum breakdown voltage of 7.2 V and a maximum reverse stand-off voltage of 6.5 V, it clamps voltage transients effectively, safeguarding downstream components. The device supports a wide operating temperature range from -55°C to +150°C, enabling reliable performance under harsh environmental conditions.

The SMBJ6.5CA-TR's compact form factor with dimensions 4.6 mm (length) x 3.95 mm (width) x 2.45 mm (height) allows easy integration into space-constrained electronic designs. Its high peak pulse current capacity of 276 A provides ample capability to handle powerful transient surges from inductive loads, switching power supplies, and lightning-induced events.

This transient voltage suppressor diode is ideal for use in industrial electronics, automation systems, power supply protection, and general electronic equipment requiring sensitive circuit protection. Its bi-directional nature allows versatile installation in AC or DC voltage environments.

Single diode configuration suitable for bidirectional voltage suppression. Surface mount DO-214 package for efficient PCB integration. 600 W peak pulse power rating for robust transient protection. Operating temperature range from -55°C to 150°C ensures durability.

Compact 4.6 x 3.95 x 2.45 mm size supports space-saving layouts. Maximum peak pulse current of 276 A to handle severe surges. Low maximum reverse leakage current of 20 μA minimizes power loss. Clamping voltage of 14.5 V provides effective voltage spike suppression.

Suitable for industrial, automotive, and consumer electronics applications. Compatible with automated manufacturing and high-volume assembly lines. Explore more STMicroelectronics components and TVS Diode solutions at EnvMart for reliable and high-performance electronic protection products.
